ORDERING INFORMATION
Description Order Code
TPT320 voltage tester CAT IV 600 V 1004-304
Included Accessories
2 x GS38 tips
Optional Accessories
MPU690 Proving unit 1001-561
Euro spare metal tips (10 pcs supplied in bag) 2005-269
UK GS38 spare tips (10 pcs supplied in bag) 2005-268
Pouch 2005-536
SPECIFICATIONS
AC/DC volts 12 to 690 V
Battery (consumption) 80 mA
Compliance TUV Rheinland GS tested
EN 61243-3:2010
EN 61010-1:2010
Continuity <500 kΩ
Display Optical 3 digit, LCD / 8 red LEDs
voltage and polarity indication
/ 2 green LEDs rotary indication / 2
red LEDs for continuity and dangerous
voltage indication
Duty Cycle 30s On / 240s Off
Frequency measurement
range
40 to 400Hz
LCD ±3% ±5 digits
Operating panel Torch button / buzzer for continuity
and dangerous voltage indication
Phase indication >90 V AC ±10%
Polarity Yes
Power supply 2 x 1.5 V batteries type AAA LR03
Safety protection CAT IV 600 V
Test current range <3.5 mA
Torch White LED
Humidity 85% RH
IP rating IP64
Maximum altitude 2000 metres
Operating temperature
range
-5 °C - +40 °C
Storage temperature
range
-20°C - +70°C
Dimensions 67 mm (W) x 205 mm (H) x 19 mm (D)
Lead length 1.2 metres
Weight 180 g
