5.9. Connecting the audio output / headphones /
speaker boxes
Connect active speaker boxes for playback or an audio connection cable for record-
ing. Read the operating instructions for your stereo to find out which input you
need to use (usually Line In or Aux).
` Connect the cable to the green socket on the back of your PC with the 3.5mm
stereo jack.
5.9.1. Connecting the headphones
Connect the headphones/earphones here.
` Connect the cable to the green socket on the back of your PC with the 3.5mm
stereo jack.
WARNING!
Damage to hearing!
Excessive volumes when using headphones or ear-
phones, as well as changes to the default settings on
the equaliser, driver, software or operating system, can
generate excessive acoustic pressure that can cause
hearing loss.
` Before pressing play, set the volume to the lowest
setting.
` Start playback and increase the volume to a com-
fortable level.
5.9.2. PCs with surround sound system (Surround) (optional)
Connect the surround sound system as follows:
` Connect the cable of the front speaker into the green socket marked FS.
` Connect the boxes for emitting sound to the back of the room to the RS socket.
` Connect a central speaker or subwoofer to the CS socket.
` Connect other speakers for emitting sound to the rear of the room to the SS
socket.
A digital audio output (SPDIF) (optional) can be connected with an optical or coaxi-
al cable.
` Connect an optical cable to the optical socket or a coaxial cable to the coaxial
socket.
` Connect the other end of the cable to an audio device that has a corresponding
digital input.
