Rear panel connections
Mains Power 100v > 240v 50/60 Hz 300W A/C. Terminated to rear panel IEC connector.
LAN Female RJ-45 - transports control and communications via Ethernet on
Category 5e (CAT5e) cabling.
XDAB Dual Female RJ-45 Connector - proprietary LVDS signaling via shielded
Category 6 (CAT6) cable terminated with shielded male RJ- 45 jacks, max.
length 10 feet (3m). NION n3, n6 only.
RS-232 Serial Female DB-9 - supports general purpose RS-232 communications.
RS-485/422
Serial
Female DB-9 - supports bi-directional RS-485 half-duplex and RS-422 full
duplex multidrop serial communications.
Audio Network
Module
CobraNet CM-1 Module with 2 Female RJ-45 connectors -
transports digital audio via CobraNet audio network
on Category 5e (CAT5e) cabling terminated with
male RJ-45 jacks.
Dante DLM Module with 2 Female RJ-45 connectors -
transports digital audio via Dante audio network on
CAT-5 or better cabling terminated with male RJ-45
plugs.
GPIO Female DB-25 - breaks out configurable general purpose logic and status
connections to external DIN terminating block (optional).
I/O Bays Proprietary I/O card slots. Support for proprietary audio and interface
cards, available separately.
