NION Hardware Manual
May 17, 2011 Version 1.6.2a.0 21
Acoustic echo cancellation can be applied to mic input or internal audio input channels
(from NION)
48 or 96 kHz audio sampling rate supported
High reliability DIN connector to backplane, using slide rail for alignment
Mini-Euro connectors for easy input connection.
This type of card can be installed in any of the available expansion slots at the rear of the
NION.
NIO-AES
Eight channel pairs of AES3 input or output audio channels
Input or output channel pairs may be selected individually in software
S/PDIF supported and enabled with onboard dip switches
Sample rate converters defeatable in the NWare control software
48 or 96 kHz audio sampling rate supported
High reliability DIN connector to backplane, using slide rail for alignment
Mini-Euro connectors for easy input connection.
This type of card can be installed in any of the available expansion slots at the rear of the
NION.
