www.mechtechsys.com

Made in the USA

MECH-TECH SYSTEMS

‘1911’ Model CCU

Operation & Maintenance Manual

- Safety First-

Read and understand this manual before attempting

to use this product! If you have any questions call:

1-866-433-2122

(Toll Free!)

Mech-Tech Systems Inc.

3243 US Highway 93 South

Kalispell, MT 59901

www.mechtechsys.com

1-866-433-2122

For one year from the date of purchase to the ORIGINAL

owner, if the Mech-Tech Systems CCU is operated and

maintained according to the instructions in the owner's

manual, Mech-Tech Systems will repair or replace, free of

charge, any part found to be defective in material or

workmanship. Customers are responsible for freight

charges for returning products to the factory. Contact

Mech-Tech Systems for return details.

This warranty does not cover: Items which become worn

during normal use. Repairs necessary because of opera-

tor abuse, negligence, accident, or failure to maintain or

operate according to the owner's manual. Unarthorized

modifications to the CCU.

WARRANTY

Summary of content (12 pages)

PAGE 1
MECH-TECH SYSTEMS ‘1911’ Model CCU Operation & Maintenance Manual WARRANTY For one year from the date of purchase to the ORIGINAL owner, if the Mech-Tech Systems CCU is operated and maintained according to the instructions in the owner's manual, Mech-Tech Systems will repair or replace, free of charge, any part found to be defective in material or workmanship. Customers are responsible for freight charges for returning products to the factory. Contact Mech-Tech Systems for return details.
PAGE 2
Mech-Tech CCU Operation & Maintenance Manual - 1911 Model 1) SAFETY ADDENDUM This is a safely addendum to follow page 1. Carefull reading of this manual will reveal that the bolt must be retracted before any attempt to remove the pistol lower unit. There can occur a unique circumstance where a cartrige gets stuck in the chamber and the bolt cannot be retracted. The stuck cartridge may not be seated fully into the chamber and this will prevent the fireing of the CCU because the bolt is not fully forward.
PAGE 3
Mech-Tech CCU Operation & Maintenance Manual - 1911 Model 1) Safety Inherent in virtually all products is the capacity for unsafe use. This applies to everything from automobiles to egg beaters. The Mech-Tech CCU is a piece of mechanical machinery and must be operated with the observation of proper safety procedures. Read and understand this entire document before attempting operation or maintenance of the CCU.
PAGE 4
MINI-QUAD PICATINNY RAILS COCKING HANDLE MOLDED FOREGRIP M4 FRONT SIGHT FIG. 1 MONORAIL 6” PICATINIY RAIL REMOVEABLE STOCK M4 CARRY HANDLE REAR SIGHT M4 STOCK M4 STOCK ADAPTER EJECTION PORT 1911 LOWER UNIT FIG.
PAGE 5
WIDER PORTION OF SLOT - START BY PLACING FRAME RAILS HERE AND THEN SLIDE FORWARD ENSURING FRAME RAIL GROOVES ENGAGE EDGES OF NAROWER HOUSING SLOT A FRAME RAILS FIG. 3 A NARROW PORTION OF SLOT WHICH ENGAGES 1911 FRAME RAIL GROOVES FIG.
PAGE 6
muzzle end of the housing. Be certain that the 1911 lower unit is in full contact with the CCU housing when the ‘rails’ are in their correct opening and only then push the lower forward. Assembly of the 1911 lower into the housing may be easier with the whole thing upside-down. Be cautious to remember that unintentional release of the CCU bolt during assembly can injure a finger! A word here may be helpful as to senses of direction as used in this manual.
PAGE 7
3) Maintenance The CCU does not ‘field strip’. The main areas of concern are lubrication and cleaning. The cleaning of the barrel bore and chamber is performed using the same techniques as with other firearm systems. Use a cleaning rod and a bore brush followed by rod and patch. Use any of the commonly available bore solvents for this. The barrel is stainless steel and does not require any lubrication after cleaning. Lock back the bolt in the open position while cleaning the bore.
PAGE 8
FRONT BUFFER FORGRIP FIG. 7 BARREL SUBASSEMBLY SHORT RAIL MAIN HOUSING SUBASSEMBLY M4 STOCK HOOK BARREL SUPPORT MOUSE TRAP SPRING FIG.
PAGE 9
FIG. 9 SAFETY SPRING BOLT CHANNEL SUBASSEMBLY BOLT INSERT BOLT CHANNEL 13 (Do not use the springless bolt handles with a housing designed for the spring loaded bolt handles and vice versa.) The next step in the CCU disassembly is to remove a total of 8 SHCS’s - 4 on each side of the housing at the front. The heads of these 8 screws also serve to locate the plastic foregrip. You will need a 9/64” hex wrench. The screws are 8-32 SHCS’s which are 5/16” long. Do not substitute screws of a different length.
PAGE 10
Keep the right thumb firmly over the post so as to prevent the recoil spring from leaving the post. Now separate the bolt from the barrel by about 3 inches. Do this by pulling the assemblies apart along an axis parallel to the barrel. You will notice that the recoil spring has stretched. Carefully tilt the barrel, using your right thumb as the approximate pivot point, so that the portion of the barrel which is to the rear of the support moves out of the channel in the bolt.
PAGE 11
1911 BOLT INSERT BOLT CHANNEL RECOIL SPRING INSERT BODY FIG. 6 FIRING PIN SPRING A B BARREL SUPPORT BARREL C D A - EXTRACTOR PIVOT PIN B - FIRING PIN RETAINING PIN C - EXTRACTOR SPRING D - EXTRACTOR FIG.
PAGE 12
RAIL MOUNTING THREADED STUDS MOUSETRAP SPRING 19 FIG. 10 When the extractor pivot pin is removed the extractor falls free. Note carefully how the extractor is oriented. The ‘claw’ faces inward. The extractor has two small holes at one end. The rear-most hole is larger and it is through this hole that the pivot pin must go when reassembling. The smaller hole just forward of the pivot pin hole is for the extractor spring.
