■ Model Encoding

■ Description

■ Features

File Name:IDLV-45-SPEC 2018-01-10

■ Applications

M M

Rated wattage

Series name

IDLV

IDLV-45 series is a 45W AC/DC LED driver featuring the constant voltage mode PWM style output

design. IDLV-45 operates from 90 295VAC and offers models with different rated voltage ranging～

between 12V and 60V. Thanks to the high efficiency up to 90%, with the fanless design, the entire

series is able to operate for -20 ~+85 case temperature under free air convection. IDLV-45 is℃℃

equipped with various function options, such as dimming methodologies, so as to provide the design

flexibility for LED lighting system.

45W PWM Output LED Driver

IDLV-45 series

Rated output voltage(12/24/36/48/60V)

Function options

Type

Blank

Function Note

In Stock

2 in 1 dimming (0~10VDC and 10V PWM)

2 in 1 dimming

and Auxiliary DC output

LED strip lighting

Indoor LED lighting

LED decorative lighting

LED architecture lighting

Constant Voltage PWM style output

with frequency 1KHz

Plastic housing with class II design

Built-in active PFC function

No load power consumption<0.5W(Blank-Type)

Function options: 2 in 1 dimming (dim-to-off);

Auxiliary DC output

3 years warranty

SELV

IS 15885(Part 2/Sec13)

R-41027766

THOMAS SAMUEL

(for IDLV-45-12,24,48 only)

Summary of content (6 pages)

PAGE 1
I D LV- 4 5 45W PWM Output LED Driver series IS 15885(Part 2/Sec13) M SELV M THOMAS SAMUEL THOMAS SAMUEL R-41027766 S&E (for IDLV-45-12,24,48 only) ■ Features Constant Voltage PWM style output ■ Applications with frequency 1KHz Plastic housing with class II design Built-in active PFC function No load power consumption<0.
PAGE 2
I D LV- 4 5 45W PWM Output LED Driver series SPECIFICATION MODEL DC VOLTAGE OUTPUT IDLV-45 -12 IDLV-45 -24 IDLV-45 -36 IDLV-45 -48 IDLV-45 -60 12V 24V 36V 48V 60V RATED CURRENT 3.0A 1.88A 1.25A 0.94A 0.75A RATED POWER 36W 45.12W 45W 45.12W 45W 88% 90% DIMMING RANGE 0~100% VOLTAGE TOLERANCE ±10% PWM FREQUENCY (Typ.) 1KHz(±20%) SETUP TIME Note.3 500ms / 230VAC 1200ms/115VAC AUXILIARY DC OUTPUT Note.4 Nominal 12V(deviation 11.4~12.
PAGE 3
I D LV- 4 5 45W PWM Output LED Driver series DIMMING OPERATION ACL ACL ACN ACN TB1 DIM+ DIMVo+ TB2 Vo- ※ Dimming principle for PWM style output Dimming is achieved by varying the duty cycle of the output current.
PAGE 4
I D LV- 4 5 45W PWM Output LED Driver series 100 100 80 80 70 70 60 60 LOAD (%) LOAD (%) OUTPUT LOAD vs TEMPERATURE 40 20 -20 -10 0 10 20 30 40 20 (HORIZONTAL) 40 -20 -10 0 15 30 45 60 85 (HORIZONTAL) Tcase (℃) AMBIENT TEMPERATURE,Ta (℃) STATIC CHARACTERISTIC POWER FACTOR (PF) CHARACTERISTIC ※ Tcase at 75℃ 100 for 12V model 90 1.00 80 0.95 for others 277(45W) 0.90 60 115(36W) 0.85 50 0.80 40 90 230(45W) PF LOAD (%) 70 100 135 180 200 0.
PAGE 5
I D LV- 4 5 45W PWM Output LED Driver series BLOCK DIAGRAM fosc : 70~150KHz AUX+(for A-Type) AUX-(for A-Type) RECTIFIERS EMI FILTER & RECTIFIERS I/P POWER SWITCHING RECTIFIERS & FILTER Vo+ VoDIM+ DIM- CURRENT LIMIT DETECTION CIRCUIT O.L.P. PWM&PFC CONTROL MECHANICAL SPECIFICATION ※ Blank-Type Case No.IDLC-45A Unit:mm 120 tc 6.5 : Max. Case Temperature 6.5 1 2 TB1 3 4 tc 30 30 6.5 75 1 2 3 TB2 4 3 25 6.5 Terminal Pin No. Assignment(TB1) Pin No.
PAGE 6
I D LV- 4 5 45W PWM Output LED Driver series ※ A-Type 120 tc 6.5 : Max. Case Temperature 6.5 1 2 3 TB1 4 tc 30 30 6.5 75 1 2 3 TB2 4 5 6 3 25 6.5 Terminal Pin No. Assignment(TB1) Pin No. 1 2 3 4 Assignment ACL ACL ACN ACN Terminal Pin No. Assignment(TB2) Pin No. 1 2 3 Assignment DIM+ DIMVo+ Pin No. 4 5 6 Assignment VoAUX+ AUX- INSTALLATION MANUAL Please refer to : http://www.meanwell.com/manual.
