Data Sheet

480W Constant Power Mode LED Driver
HVGC-480 series
File Name:HVGC-480-SPEC 2018-09-30
MECHANICAL SPECIFICATION
Case No. 251 Unit:mm
※AB-Type
※Blank-Type
FG (Green/Yellow)
AC/L(Brown)
AC/N(Blue)
SOOW 17AWG 3C & H07RN-F 3 1.0mm
2
××
300 20±
ψ×4.5 4PL
Vo-(Blue)
Vo+(Brown)
 : Max. Case Temperature
tc
8.9
15
15
78
125
13.4
235.2
262
43.8
113.8
58
tc
SOOW 17AWG 2C & H07RN-F 2 1.0mm
2
××
SJOW 17AWG 2C & H05RN-F 2 1.0mm
2
××
DIM-(Black)**
DIM+(Gray)*
Io
ADJ.
SOOW 17AWG 2C & H07RN-F 2 1.0mm
2
××
FG (Green/Yellow)
AC/L(Brown)
AC/N(Blue)
ψ×4.5 4PL
 : Max. Case Temperature
tc
8.9
15
15
78
125
13.4
235.2
262
43.8
113.8
58
tc
Vo-(Blue)
Vo+(Brown)
300 20±
SOOW 17AWG 3C & H07RN-F 3 1.0mm
2
××
330 20±
300 20±
300 20±
