6W SIP Package DC-DC Regulated Converter

SPBW06 & DPBW06

series

Installation Manual

Please refer to : http://www.meanwell.com/manual.html

+Vin

O/ONFF

-Vin

2~4mA

current

source

Application circuit

The remote ON/OFF input feature of the converter allows external circuitry to turn the converter ON or OFF. Active-high remote ON/OFF is available as

standard. The converter is turned ON if the remote ON/OFF pin is open circuit. Supply the ON/OFF pin at 2mA to 4mA will turn the converter OFF. The

signal level of the ON/OFF pin is defined with respect to ground. If not using the ON/OFF pin, leave the pin open (module will be ON, recommended

application as below)

ON/OFF pin appliend current via 1KΩ

EMC Suggestion Circuit

※Required external components to meet EN55032 class A/B emission are as below:

SPBW06 / DPBW06

+Vin

-Vin

Load

+Vout

-Vout

+Vin

-Vin

+Vout

-Vout

C1 C2

E 55022 lassAN C E 55022 lass BNC

Model No.

C1 C1C2 C2C3 C3C4 C4L1 L1

SPBW06F-03

10 F/50V

μ NC 150pF/2KV 150pF/2KV 10 Hμ 10 F/50Vμ NC 1500pF/2KV 1500pF/2KV 10 Hμ

SPBW06F-05

10 F/50V

μ NC 150pF/2KV 150pF/2KV 10 Hμ 10 F/50Vμ NC

1500pF/2KV 1500pF/2KV

10 Hμ

SPBW06F-12

10 F/50V

μ NC 150pF/2KV 150pF/2KV 10 Hμ 10 F/50Vμ NC

1500pF/2KV 1500pF/2KV

10 Hμ

DPBW06F-15

10 F/50V

μ NC 150pF/2KV 150pF/2KV 10 Hμ 10 F/50Vμ NC

1500pF/2KV 1500pF/2KV

10 Hμ

DPBW06F-05

10 F/50V

μ NC 150pF/2KV 150pF/2KV 10 Hμ 10 F/50Vμ NC

1500pF/2KV 1500pF/2KV

10 Hμ

DPBW06F-12

10 F/50V

μ NC 150pF/2KV 150pF/2KV 10 Hμ 10 F/50Vμ NC

1500pF/2KV 1500pF/2KV

10 Hμ

DPBW06F-15

10 F/50V

μ NC 150pF/2KV 150pF/2KV 10 Hμ 10 F/50Vμ NC

1500pF/2KV 1500pF/2KV

10 Hμ

SPBW06G-03

1 F/100V

μ NC 150pF/2KV 150pF/2KV 10 Hμ 2.2 F/100Vμ

2.2 F/100Vμ

1500pF/2KV 1500pF/2KV

10 H

SPBW06G-05

1 F/100V
