Data Sheet

■ Model Encoding
SIP8 package with industry standard pinout
4:1 ultrawide input range
Operating temperature range -40 ~ +85
℃
No minimum load required
High efficiency up to 89%
Protections: Short circuit (Continuous) / Overload
1.5KVDC I/O isolation
Remote ON/OFF control
3 years warranty
■ Features
■ Applications
File Name:SPBW06,DPBW06-SPEC 2017-03-06
6W SIP Package DC-DC Regulated Converter
SPBW06 & DPBW06 series
Telecom datacom system/
Wireless network


Industrial control facility
Instrument
Analyzer
Detector
Data switch
■ Description
SP and DP series are W isolated and module type DC-DC converter with SIPBW06 BW06 6 regulated 8
package. It features international standard pins, a high efficiency up to 8 %, working temperature 9 wide
range -40~+ , . KVDC I/P-O/P isolation voltage, -mode short circuit protection, etc. 85 1 5 continuous℃
The models account for different input voltage and various
9~36V and 18~75V 4:1 wide input range,
output voltage, . /5V/12V/15V single output and ±5V/±12V/±15V dual outputs, which are 3 3V for for
suitable for all kinds of systems, uch as industrial control, telecommunication field, distributed power
s
architecture, and so on.
Output voltage (3 3 5 5. / / / ± /± /±12 15Vdc 12 15Vdc)，
Rated wattage
Input voltage (F: 9~36Vdc G: 18~75Vdc)，
Series name
- 12S PBW06 F
S:Single output
D:Dual output
{
