Operator’s Guide
Six Equal Sized Compressors, Six Circuits, No WRV
Only one sequence is provided so the user makes no selections.
• Total cooling stages = 6.
• Maximum cooling stages is always set to 6.
• The Staging sequence is the Standard sequence that contains the enabled Stage 1
Compressor with the fewest run hours. Compressors in disabled circuits are ignored when
only enabled compressor run hours are compared.
• The Compressor Sequence changes only when the compressor stage is Maximum cooling
stages or zero. This means that disabling and re-enabling the compressors or turning the unit
off and on may be necessary to cause sequence changes.
• The same staging sequence is used whether a circuit is disabled or not. This means that units
will remain at a stage for an extra stage time when staging up if a disabled circuit is added at
that stage. It also means that units will remain at a stage for an extra stage times when
staging down if a disabled circuit is turned off at that stage.
• Any compressor on the disabled circuit stays off if it is already off and is turned off if it is
on.
Six Equal Sized Compressors, Six Circuits, Water Regulating Valve
Only one sequence is provided so the user makes no selections.
•
Total cooling stages = 6.
• Maximum cooling stages is always set to 6.
• If both circuit # 1 and circuit # 2 are enabled, the staging sequence is Std-1 if
compressor # 1 has fewer hours than compressor # 2, and the staging
sequence is Std-2 if compressor # 1 does not have fewer hours than
compressor # 2.
• If Circuit # 1 is disabled, the staging sequence is Std-2.
• If Circuit # 2 is disabled, the staging sequence is Std-1.
• If both circuit # 1 and circuit # 2 are disabled, the staging sequence is Std-1.
Only compressors 3, 4, 5, and 6 are used.
• The Compressor Sequence changes based on Run Time only when the
compressor stage equals Maximum cooling stages or zero. This means that
Table 64: Alternate Staging
Alternate Staging
Staging Sequence Stage 1
Comps
Stage 2
Comps
Stage 3
Comps
Stage 4
Comps
Stage 5
Comps
Stage 6
Comps
Alt-1 1 1,3 1,3,5 1,2,3,5 1,2,3,4,5 1,2,3,4,5,6
Alt-2 2 2,4 2,4,6 1,2,4,6 1,2,3,4,6 1,2,3,4,5,6
Alt-3 3 3,5 1,3,5 1,3,4,5 1,3,4,5,6 1,2,3,4,5,6
Alt-4 4 4,6 2,4,6 2,3,4,6 2,3,4,5,6 1,2,3,4,5,6
Alt-5 5 1,5 1,3,5 1,3,5,6 1,2,3,5,6 1,2,3,4,5,6
Alt-6 6 2,6 2,4,6 2,4,5,6 1,2,4,5,6 1,2,3,4,5,6
StgdClgCap 17% 33% 50% 67% 83% 100%
Table 65: Standard Staging
Standard Staging
Staging Sequence Stage 1
Comps
Stage 2
Comps
Stage 3
Comps
Stage 4
Comps
Stage 5
Comps
Stage 6
Comps
Std-1 1 1,2 1,2,3 1,2,3,4 1,2,3,4,5 1,2,3,4,5,6
Std-2 2 2,3 2,3,4 2,3,4,5 2,3,4,5,6 1,2,3,4,5,6
Std-3 3 3,4 3,4,5 3,4,5,6 1,3,4,5,6 1,2,3,4,5,6
Std-4 4 4,5 4,5,6 1,4,5,6 1,2,4,5,6 1,2,3,4,5,6
Std-5 5 5,6 1,5,6 1,2,5,6 1,2,3,5,6 1,2,3,4,5,6
Std-6 6 1,6 1,2,6 1,2,3,6 1,2,3,4,6 1,2,3,4,5,6
StgdClgCap 17% 33% 50% 67% 83% 100%
