Keypad/Display Menu Structure
Adv Setup Settings Menu
The Advanced Setup Settings Menu should only be accessed by trained service
personnel.
The Advanced Setup Settings Menu can be accessed when a level 2 password has been
entered.
Table 50: Adv Setup Settings Menu
Menu Display Name Item Display Name Default Setting Range Password Level
Adv Setup Settings 0-30% OA Max = 30% 0-100% 2
Des Clg Spd= 100% 0-100% 2
Unocc Diff= 3d°F 0-10d°F 2
Service Time= 20s 0-300s 2
DLS Strt Mon= Mar Jan 2
Feb
Mar
Apr
May
Jun
Jul
Aug
Sep
Oct
Nov
Dec
DLS Strt Wk= 2ndWeek 1stWeek 2
2ndWeek
3rdWeek
4thWeek
5thWeek
DLS End Mon= Nov Jan 2
Feb
Mar
Apr
May
Jun
Jul
Aug
Sep
Oct
Nov
Dec
DLS End Week= 1stWeek 1stWeek 2
2ndWeek
3rdWeek
4thWeek
5thWeek
DLS Active= Yes Yes/N o 2
Gas Derate V= 10V 0-10V 2
Max Purge Hld 10-180s 2
Rapid Start= No No 2
Yes
Rapid Start Tm= 10min 0-20min 2
Name POL687 ****** 2
RH Sens Type VDC VDC/mA 2
RH Min Signal 0.0V 0.0-20V/mA 2
RH Min Signal 10.0V 0.0-20V/mA 2
