Keypad/Display Menu Structure
Manual Control Menu
The manual control of operation is a function that is used for operating the unit during a
service call only. The unit must not be operated in this mode for any extended period of time.
Table 39: Manual Control Manual
Menu Display Name Item Display Name Default Setting Range Password Level
Manual Control Manual Ctrl= Normal Normal 4
ManCtrl
Supply Fan= Off Off 4
On
RF/EF VFD= Off Off 4
On
SAF Spd Cmd= 0% 0-100% 4
RF/EF Spd Cmd= 0% 0-100% 4
OAD/Econo= 0% 0-100% 4
OAD OpCl= Close Close 4
Open
Comp 1 = Off Off 4
On
Comp 2 = Off Off 4
On
Comp 3 = Off Off 4
On
Comp 4 = Off Off 4
On
Comp 5 = Off Off 4
On
Comp 6 = Off Off 4
On
Comp 7 = Off Off 4
On
Comp 8 = Off Off 4
On
CFan Outpt 1= Off Off 4
On
CFan Outpt 2= Off Off 4
On
CFan Outpt 3= Off Off 4
On
BP/WR Valve= 0% 0-100% 4
CW Valve= 0% 0-100% 4
ECond VFD= Off Off 4
On
ECFan Spd Cmd= 0% 0-100% 4
EC Drn Valve= Close Close 4
Open
Sump Pump= Off Off 4
On
Main Gas Vlv= Close Close 4
Open
Htg Valve= 0% 0-100% 4
F&BP Damper= 0% 0-100% 4
Htg Stg 1= Off Off 4
On
Htg Stg 2= Off Off 4
On
Htg Stg 3= Off Off 4
On
Htg Stg 4= Off Off 4
On
