Specifications

Model : M4MST151515AR

1. ASSY., BASE PAN 14. ASSY., CAP. TUBE 2 ( 1.5 HP )

2. ASSY., INS. PARTITION 15. ASSY., CAP. TUBE 3 ( 1.5 HP )

3. ASSY., OUTDOOR COIL MAIN 16. ASSY., SIDE PANEL RIGHT INS.

4. ASSY., VALVE PLATE MAIN 17. PANEL, ASSY. SIDE LEFT

5. ASSY., 3-WAY VALVE ( ½” ) 18. ASSY., ORIFICE 19” PROPELLER

6. ASSY., 3-WAY VALVE ( ½” ) 19. BRACKET, MOTOR

7. SCREW, TRUSS HEAD PHILLIP 20. ASSY., FAN MOTOR

8. ASSY., 2-WAY VALVE ( ¼” ) 21. PROPELLER, FAN ( 19” )

9. ASSY., COMP. 4PS2250AA 22. ASSY., PANEL TERMINAL BOX

10. ASSY., 4WV COMP. 1 ( 1.5 HP ) 23. FAN, GUARD

11. ASSY., 4WV COMP. 2 ( 1.5 HP ) 24. PANEL, TOP

12. ASSY., 4WV COMP. 3 ( 1.5 HP ) 25. PANEL, FRONT

13. ASSY., CAP. TUBE 1 ( 1.5 HP )
