Specifications

Model : M4MST101015AR

1. ASSY., BASE PAN 15. ASSY., CAP. TUBE 1 ( 1.0 HP )

2. COMPRESSOR, RUBBER GROMMET 16. ASSY., CAP. TUBE 2 ( 1.0 HP )

3. ASSY., INS. PARTITION 17. ASSY., CAP. TUBE 3 ( 1.5 HP )

4. ASSY., OUTDOOR COIL MAIN 18. ASSY., SIDE PANEL RIGHT INS.

5. ASSY., COMP. 4PS1640AA 19. PANEL, SIDE LEFT

6. ASSY., COMP. 4PS2250AA 20. ASSY., ORIFICE 19” PROPELLER

7. ASSY., VALVE PLATE MAIN 21. BRACKET, MOTOR

8. ASSY., 3-WAY VALVE ( ½” ) 22. ASSY., FAN MOTOR

9. ASSY., 3-WAY VALVE ( 3/8” ) 23. PROPELLER, FAN ( 19” )

10. SCREW, TRUSS HEAD PHILLIP 24. ASSY., PANEL TERMINAL BOX

11. ASSY., 2-WAY VALVE ( ¼” ) 25. FAN, GUARD

12. ASSY., 4WV COMP. 1 ( 1.0 HP ) 26. PANEL, FRONT

13. ASSY., 4WV COMP. 2 ( 1.0 HP ) 27. PANEL, TOP

14. ASSY., 4WV COMP. 3 ( 1.5 HP )
