Specifications

Model : M4MST101010AR

1. ASSY., BASE PAN 14. ASSY., CAP. TUBE 1 ( 1.0 HP )

2. COMPRESSOR, RUBBER GROMMET 15. ASSY., CAP. TUBE 2 ( 1.0 HP )

3. ASSY., INS. PARTITION 16. ASSY., CAP. TUBE 3 ( 1.0 HP )

4. ASSY., OUTDOOR COIL MAIN 17. ASSY., SIDE PANEL RIGHT INS.

5. ASSY., COMP. 4PS1640AA 18. PANEL, SIDE LEFT

6. ASSY., VALVE PLATE MAIN 19. ASSY., ORIFICE 19” PROPELLER

7. ASSY., 3-WAY VALVE ( 3/8” ) 20. BRACKET, MOTOR

8. ASSY., 3-WAY VALVE ( 3/8” ) 21. ASSY., FAN MOTOR

9. SCREW, TRUSS HEAD PHILLIP 22. PROPELLER, FAN ( 19” )

10. ASSY., 2-WAY VALVE ( ¼” ) 23. ASSY., PANEL TERMINAL BOX

11. ASSY., 4WV COMP. 1 ( 1.0 HP ) 24. FAN, GUARD

12. ASSY., 4WV COMP. 2 ( 1.0 HP ) 25. PANEL, TOP

13. ASSY., 4WV COMP. 3 ( 1.0 HP ) 26. PANEL, FRONT
