Specifications

Model : MMSH8K8A

1. BACK PANEL 14. SQUARE WASHER

2. TOP PANEL 15. FAN BLADE

3. CONDENSER COIL ASSY 16. RING WASHER

4. HEXAGON NUT 17. FAN MOTOR

5. FLAT WASHER 18. FAN MOTOR BRACKET

6. ROTARY COMPRESSOR A 19. BASE PAN ASSEMBLY

7. ROTARY COMPRESSOR B 20. PARTITION ASSEMBLY

8. RUBBER GROMMET 21. TERMINAL BOX PANEL WIRING ASSEMBLY

9. TRUSS HEAD PHILLIP SCREW 22. SIDE PANEL

10. SPRING WASHER 23. ACCESS PANEL

11. MOUNTING PLATE ASSEMBLY 24. VALVE PLATE ASSEMBLY

12. FRONT PANEL 25. RUBBER DAMPER

13. HEX. NUT 3/8” 26. TERMINAL BOX COVER
