User manual

2
CLI Commands
2-157
show
Purpose This command displays information from the name server database
for devices attached to this switch. Note that it is possible to have
more than one device per port for any public loop devices attached to
an FL Port.
Parameters This command has no parameters.
Command Example
Root> show nameServer
Output The device information data is displayed as a table that includes the
following properties.
Type The type (N, NL, F/NL, F, FL, E, B).
Port Id The 24-bit Fibre Channel address.
Port Name The port WWN of the attached device.
Node Name The node WWN of the attached device.
COS The class of service (for example, 1; 2; 3; 4; 5; 6;
F; 1,2; 2,3).
FC4 Types The FC4 types registered for this device. One or
more numbers display in this field. The
numbers in this field correspond to the list at
the bottom of the output example below.
