User Manual

- 23 -
ITEM PART NO. DESCRIPTION GPR65 GPR68 GPR68R GPR77
1. 00032 KEY, 3/16” SQUARE x 1-5/8” LONG 1 1 1
00808 KEY, 1/4” SQUARE x 1-3/4” LONG 1
2. 01185 V-BELT, (A-33) 1 1 1
05831 V-BELT, (A-35) 1
3. 01444 ENGINE, HONDA, GX160 1 1
15674 ENGINE, HONDA, GX270 1
17370 ENGINE, ROBIN, EX17 1
4. 07636 EXHAUST DEFLECTOR 1 1
5. 14429 ROD END, 1/4-28 1 1 1 1
6. 18110 SHIFTER & CABLE ASSEMBLY (Order 18109 for sleeve only) 1 1 1 1
7. 14993 WASHER, COUNTERSUNK 1 1 1
14992 WASHER, COUNTERSUNK 1
8. 16105 CLUTCH, CENTRIFUGAL 1 1 1
19127 CLUTCH, CENTRIFUGAL 1
9. 16849 BASEPLATE (GPR65) 1
16992 BASEPLATE (GPR68) 1 1
19101 BASEPLATE (GPR77) 1
10. 16852 ENGINE DECK 1 1 1
19105 ENGINE DECK 1
11. 16861 BELTGUARD 1 1 1
16862 BELTGUARD 1
12. 16975 OIL DRAIN LINE, HONDA 5.5hp 1 1
16974 OIL DRAIN LINE, HONDA 8hp 1
18767 OIL DRAIN LINE 1
13. 16986 ROLLCAGE 1 1 1
19119 ROLLCAGE 1
14. 17006 EXCITER ASSEMBLY, CAST IRON 1 1 1
19108 EXCITER ASSEMBLY GPR77 1
15. 17117 SHOCKMOUNT, 2.95” OD x 2.17” LONG 4 4 4 4
16. 19124 EXTENSION, BELT GUARD 1
17. 19136 SPACER, CLUTCH, 1-3/8 OD x 5/8 LG 1
18. F0203HTB TAPPING BOLT, #8 x 3/8” 2 2
19. F042006FWS FLANGE LOCKING SCREW, 1/4-20 x 3/4” 4 4 4 4
20. F042006HCS HEX HEAD CAP SCREW, 1/4-20 x 3/4” 1 1 1 1
21. F0420HN HEX NUT, 1/4-20 1 1 1 1
22. F0428HN HEX NUT, 1/4-28 1 1 1 1
23. F051812HCS HEX HEAD CAP SCREW, 5/16-18 X 1-1/2” 4 4 4
F051814HCS HEX HEAD CAP SCREW, 5/16-18 X 1-3/4” 4
24. F052408FSS FLAT HEAD SOCKET SCREW, 5/16-24 X 1” 1 1 1
F072008FSS FLAT HEAD SOCKET SCREW, 7/16-20 X 1” 1
25. F052406HCS HEX HEAD CAP SCREW, 5/16-24 X 3/4” 4
26. F05LW LOCK WASHER, 5/16” 4 4 4 8
27. F05SW WASHER, 5/16” 8 8 8 8
28. F061608FWS FLANGE LOCKING BOLT, 3/8-16 x 1” 4 4 4 4
29. F0616FN FLANGE LOCKNUT, 3/8-16 4 4 4 4
30. F071420FSS FLAT HEAD SOCKET SCREW, 7/16-14 x 2-1/2” 6 6 6 6
31. F0714HN HEX NUT, 7/16-14 6 6 6 6
32. F07LW LOCK WASHER, 7/16” 6 6 6 6
33. F081307HCS HEX HEAD CAP SCREW, 1/2-13 x 7/8” 4 4 4 4
34. F0813ELN ELASTIC LOCKNUT, 1/2-13 4 4 4 4
35. F08LW LOCK WASHER, 1/2” 4 4 4 4
36. F08SW WASHER, 1/2” 8 8 8 8
SERVICE PARTS
14477 SHIFTER, NO CABLE
19511 SHIFT HANDLE LEVER ONLY
20414 KIT, SHIFT CABLE
