User`s manual

7, 9, 10, 13 channels display mode

10.

16 channels display mode

11. LED LIGHT

The LED Light is ON under the following conditions.

‧HDD : HDD is activated

‧HDD Full : HDD is full

‧ALARM : If you want to turn off the ALARM LED light, please refer to page.13 and set the

Camera / ALARM item as OFF. (all of the cameras should be set as OFF.)

‧TIMER : When Timer is set as Enabled

‧PLAY : On Play mode

‧REC : On Recording mode

12. CAMERA (1-16)

Press the Camera Select (1-16) to select specified camera.

13. REC

Press REC to start recording.

14. REW / LEFT

‧REW : Under DMR play mode, it can play video backward at different speeds. (Press REW again to adjust

speed as 1, 2, 4, 8, 16, 32 times)

‧Left : Under setup mode, it works as Left button.

15. PLAY

Press PLAY to play recorded video.

16. STOP / DOWN

‧STOP : Under DMR Record / Play mode, it can stop the action.

‧DOWN : Under setup mode, it works as Down button.

17. PAUSE / UP

‧Pause : Under DMR play mode, it can pause the action.

‧UP : Under setup mode, it works as Up button.

18. FF / Right

‧FF : It can play video forward at high speed, and press FF again to adjust speed from 1, 2, 4, 8, 16, 32 times.

‧Right : Under setup mode, it can work as Right button.

19. POWER

Press Power to turn ON / OFF the DMR.
