MSP (Modular Sensored Power)
Suggested MSP Configurations for No Outlet Control and Circuit Metering. Please note that many other configura-
tions can be made with the modular design
Bay Technical Assoc. Inc. 5239 A Avenue Long Beach, MS 39560 Tel: [phone] Fax: [phone] [e-mail]
No Outlet Control; Metered Input; LED
208V 3ØY (3 Phase) continued
RECEPTACLES COMMUNICATIONS INTERFACE
Dimension
W-1.97” D-2.15”
Length
AMPS Input Power Total N20 C13 C19 RS-232 DIRECT IP
30A NEMA L21-30P 30 - 24 6 MSP11.03A.647A-14 $757.00 MSP11.04.647A-14 $898.00 69.0
30 - 18 12 MSP11.03A.647B-14 $782.00 MSP11.04.647B-14 $923.00 69.0
30 - 30 - MSP21.03A.637-14 $739.00 MSP21.04.637-14 $880.00 61.25
36 - 30 6 MSP11A.03A.646A-14 $773.00 MSP11A.04.646A-14 $914.00 64.5
50A CS8365CP 24 - 18 6 MSP20.03.638A-18 $997.00 MSP20.04.638A-18 $1,130.00 54.75
24 - 12 12 MSP20.03.638B-18 $1,020.00 MSP10.04.638B-18 $1,170.00 62.5
30 - 24 6 MSP10.03.647A-18 $1,030.00 MSP10.04.647A-18 $1,170.00 69.0
30 - 18 12 MSP10.03.647B-18 $1,050.00 MSP10.04.647B-18 $1,190.00 69.0
30 - 12 18 MSP10.03.647C-18 $1,070.00 MSP10.04.647C-18 $1,210.00 62.5
30 - 30 - MSP20.03.637-18 $982.00 MSP20.04.637-18 $1,120.00 61.25
36 - 30 6 MSP10A.03.646A-18 $1,040.00 MSP10A.04.646A-18 $1,180.00 64.5
36 - 24 12 MSP10A.03.646B-18 $1,070.00 MSP10A.04.646B-18 $1,210.00 64.5
60A IEC60309 24 - 18 6 MSP20.03.638A-12 $1,110.00 MSP20.04.638A-12 $1,250.00 54.75
24 - 12 12 MSP20.03.638B-12 $1,130.00 MSP10.04.638B-12 $1,290.00 62.5
30 - 24 6 MSP10.03.647A-12 $1,140.00 MSP10.04.647A-12 $1,280.00 69.0
30 - 18 12 MSP10.03.647B-12 $1,170.00 MSP10.04.647B-12 $1,310.00 69.0
30 - 12 18 MSP10.03.647C-12 $1,190.00 MSP10.04.647C-12 $1,330.00 62.5
30 - 30 - MSP20.03.637-12 $1,090.00 MSP20.04.637-12 $1,240.00 61.25
36 - 30 6 MSP10A.03.646A-12 $1,160.00 MSP10A.04.646A-12 $1,300.00 64.5
36 - 24 12 MSP10A.03.646B-12 $1,180.00 MSP10A.04.646B-12 $1,320.00 64.5
36 - 36 - MSP10.03.645-12 $1,130.00 MSP10.04.645-12 $1,270.00 62.5
230/400V 3ØY (3 Phase)
RECEPTACLES COMMUNICATIONS INTERFACE
Dimension
W-1.97” D-2.15”
Length
AMPS Input Power Total N20 C13 C19 RS-232 DIRECT IP
30A NEMA L22-30P 24 - 18 6 MSP21.03A.638A-20 $889.00 MSP20.04A.638A-20 $1,030.00 61.25
24 - 12 12 MSP21.03A.638B-20 $913.00 MSP20.04A.638B-20 $1,050.00 61.25
30 - 24 6 MSP11.03A.647A-20 $922.00 MSP10.04A.647A-20 $1,060.00 62.5
30 - 18 12 MSP11.03A.647B-20 $946.00 MSP10.04A.647B-20 $1,080.00 69
30 - 30 - MSP21.03A.637-20 $874.00 MSP20.04A.637-20 $1,010.00 61.25
36 - 30 6 MSP11A.03A.646A-20 $938.00 MSP10A.04A.646A-20 $1,070.00 64.5
36 - 24 12 MSP11A.03A.646B-20 $962.00 MSP10A.04A.646B-20 $1,100.00 64.5
36 - 36 - MSP11.03A.645-20 $914.00 MSP10.04A.645-20 $1,050.00 69
