User Manual

MSP (Modular Sensored Power)
Bay Technical Assoc. Inc. 5239 A Avenue Long Beach, MS 39560 Tel: [phone] Fax: [phone] [e-mail]
Suggested MSP Configurations for No Outlet Control and Circuit Metering. Please note that many other configura-
tions can be made with the modular design
No Outlet Control; Metered Input; LED
208V (Single Phase) continued
RECEPTACLES COMMUNICATIONS INTERFACE
Dimension
W-1.97” D-2.15”
Length
AMPS Input Power Total N20 C13 C19 RS-232 DIRECT IP
30A NEMA L6-30P 24 - 24 MSP14.03B.445-08 $553.00 MSP14.04B.445-08 $694.00 45.75
30 30 MSP27.03B.637-08 $616.00 MSP27.04B.637-08 $757.00 52.5
120/208VAC (2 Phase)
RECEPTACLES COMMUNICATIONS INTERFACE
Dimension
W-1.97” D-2.15”
Length
AMPS Input Power Total N20 C13 C19 RS-232 DIRECT IP
20A NEMA L14-20P 24 6 18 - MSP14.03B.144.345-29 $592.00 MSP14.04B.144.345-29 $733.00 45.75
25 5 10 10 MSP27.03B.136.538B-29 $689.00 MSP27.04B.136.538B-29 $830.00 52.5
30 5 25 - MSP27.03B.136.537-29 $657.00 MSP27.04B.136.537-29 $798.00 52.5
31 6 10 15 MSP17.03B.144.547C-29 $730.00 MSP17.04B.144.547C-29 $871.00 61.25
31 6 15 10 MSP17.03B.144.547B-29 $710.00 MSP17.04B.144.547B-29 $851.00 61.25
36 6 30 - MSP17.03B.144.545-29 $682.00 MSP17.04B.144.545-29 $823.00 61.25
30A NEMA L14-30P 24 6 18 - MSP14.03B.144.345-29 $592.00 MSP14.04B.144.345-29 $733.00 45.75
25 5 10 10 MSP27.03B.136.538B-25 $698.00 MSP27.04B.136.538B-25 $839.00 52.5
30 5 25 - MSP27.03B.136.537-25 $666.00 MSP27.04B.136.537-25 $807.00 52.5
36 6 30 - MSP17.03B.144.545-25 $692.00 MSP17.04B.144.545-25 $833.00 61.25
120V 3ØY (3 Phase)
RECEPTACLES COMMUNICATIONS INTERFACE
Dimension
W-1.97” D-2.15”
Length
AMPS Input Power Total N20 C13 C19 RS-232 DIRECT IP
20A NEMA L21-20P 30 30 - - MSP21.03A.636-13 $730.00 MSP21.04.636-13 $871.00 54.75
36 36 - - MSP11.03A.644-13 $725.00 MSP11.04.644-13 $866.00 62.5
30A NEMA L21-30P 30 30 - - MSP21.03A.636-14 $746.00 MSP21.04.636-14 $887.00 54.75
36 36 - - MSP11.03A.644-14 $741.00 MSP11.04.644-14 $882.00 62.5
208V 3ØY (3 Phase)
RECEPTACLES COMMUNICATIONS INTERFACE
Dimension
W-1.97” D-2.15”
Length
AMPS Input Power Total N20 C13 C19 RS-232 DIRECT IP
20A NEMA L21-20P 24 - 18 6 MSP21.03A.638A-13 $738.00 MSP21.04.638A-13 $879.00 61.25
24 - 12 12 MSP21.03A.638B-13 $763.00 MSP21.04.638B-13 $904.00 61.25
30 - 24 6 MSP11.03A.647A-13 $741.00 MSP11.04.647A-13 $882.00 69.0
30 - 18 12 MSP11.03A.647B-13 $766.00 MSP11.04.647B-13 $907.00 69.0
30 - 30 - MSP21.03A.637-13 $723.00 MSP21.04.637-13 $864.00 54.75
30A NEMA L21-30P 24 - 18 6 MSP21.03A.638A-14 $754.00 MSP21.04.638A-14 $895.00 61.25
24 - 12 12 MSP21.03A.638B-14 $778.00 MSP21.04.638B-14 $919.00 61.25
31 6 10 15 MSP17.03B.144.547C-25 $739.00 MSP17.04B.144.547C-25 $880.00 61.25
31 6 15 10 MSP17.03B.144.547B-25 $719.00 MSP17.04B.144.547B-25 $860.00 61.25
230 Yuma St., Denver, CO 80223 / Tel [phone] / Fax [phone] / www.maxpowercorp.com
©2012 MaxPower Corporaon. All rights reserved. (04/13/12)
MSP Series
MODULAR SENSORED POWER (CIRCUIT MONITORED)
