MSP (Modular Sensored Power)
Suggested MSP Configurations for No Outlet Control and Circuit Metering. Please note that many other configura-
tions can be made with the modular design
Bay Technical Assoc. Inc. 5239 A Avenue Long Beach, MS 39560 Tel: [phone] Fax: [phone] [e-mail]
No Outlet Control; Metered Input; LED
120V (Single Phase)
RECEPTACLES COMMUNICATIONS INTERFACE
Dimension
W-1.97” D-2.15”
Length
AMPS Input Power Total N20 C13 C19 RS-232 DIRECT IP
20A NEMA L5-20P 10 10 - - MSP26.03B.236-04 $420.00 MSP26.04B.236-04 $561.00 29.5
12 12 - - MSP16.03B.244-04 $430.00 MSP16.04B.244-04 $571.00 31.0
20 20 - - MSP24.03B.436-04 $508.00 MSP24.04B.436-04 $649.00 40.5
24 24 - - MSP14.03B.444-04 $525.00 MSP14.04B.444-04 $666.00 45.75
30A NEMA L5-30P 10 10 - - MSP26.03B.236-05 $449.00 MSP26.04B.236-05 $590.00 29.5
12 12 - - MSP16.03B.244-05 $459.00 MSP16.04B.244-05 $600.00 31.0
20 20 - - MSP24.03B.436-05 $537.00 MSP24.04B.436-05 $678.00 40.5
24 24 - - MSP14.03B.444-05 $554.00 MSP14.04B.444-05 $695.00 45.75
30 30 - - MSP27.03B.636-05 $627.00 MSP27.04B.636-05 $768.00 52.5
36 36 - - MSP17.03B.644-05 $641.00 MSP17.04B.644-05 61.25
208V (Single Phase)
RECEPTACLES COMMUNICATIONS INTERFACE
Dimension
W-1.97” D-2.15”
Length
AMPS Input Power Total N20 C13 C19 RS-232 DIRECT IP
20A NEMA L6-20P 8 6 2 MSP26.03B.238A-07 $437.00 MSP26.04B.238A-07 $578.00 29.5
10 8 2 MSP16.03B.247A-07 $450.00 MSP16.04B.247A-07 $591.00 31.0
10 10 - MSP26.03B.237-07 $432.00 MSP26.04B.237-07 $573.00 29.5
12 10 2 MSP16A.03B.246A-07 $460.00 MSP16A.04B.246A-07 $601.00 31.0
12 12 - MSP16.03B.245-07 $447.00 MSP16.04B.245-07 $588.00 31.0
20 16 4 MSP14.03B.447A-07 $550.00 MSP14.04B.447A-07 $691.00 45.75
20 20 - MSP24.03B.437-07 $518.00 MSP24.04B.437-07 $659.00 40.5
24 20 4 MSP14A.03B.446A-07 $564.00 MSP14A.04B.446A-07 $705.00 45.75
24 24 - MSP14.03B.445-07 $544.00 MSP14.04B.445-07 $685.00 45.75
30 30 MSP27.03B.637-07 $606.00 MSP27.04B.637-07 $747.00 52.5
30A NEMA L6-30P 8 6 2 MSP26.03B.238A-08 $452.00 MSP26.04B.238A-08 $593.00 29.5
10 8 2 MSP16.03B.247A-08 $465.00 MSP16.04B.247A-08 $606.00 31.0
10 10 - MSP26.03B.237-08 $447.00 MSP26.04B.237-08 $588.00 29.5
12 10 2 MSP16A.03B.246A-08 $475.00 MSP16A.04B.246A-08 $616.00 31.0
12 12 - MSP16.03B.245-08 $462.00 MSP16.04B.245-08 $603.00 31.0
20 16 4 MSP14.03B.447A-08 $564.00 MSP14.04B.447A-08 $705.00 45.75
20 20 - MSP24.03B.437-08 $533.00 MSP24.04B.437-08 $674.00 40.5
24 20 4 MSP14A.03B.446A-08 $579.00 MSP14A.04B.446A-08 $720.00 45.75
