Specification Sheet

PROJECT NAME:_____________________________ CATALOG NUMBER:__________________________
NOTES:______________________________________FIXTURE SCHEDULE:_________________________
Phone: [phone] | Fax: [phone] | Web: www.maxlite.com | E-mail: [e-mail]
MAX16025
Revised: 10-12-17
Page: 1 of 3
LED 6” & 8” COMMERCIAL RECESSED
RETROFIT DOWNLIGHT
ECONOMIC SERIES
RRECO
W
/V2
FAMILY SIZE
WATTAGE
(NOMIAL)
CCT TRIM
VERSION
RRECO=
Commercial Recessed Retrofit Downlight Economic Series
6=
8=
6”
8”
12=
18=
27=
12=
18=
24=
40=
12W
18W
27W
12W
18W
24W
40W
30=
40=
3000K
4000K
W=
White
V2=
Version 2
MODEL SELECTION (Full list of order codes on pg. 2) Typical order example: RRECO82440W/V2
COMPLIANT
RoHS
COMPLIANT
RoHS
PRODUCT DESCRIPTION:
The ENERGY STAR qualified eight-inch ECO Series LED
Recessed Retrofit Downlight combines low up-front cost, minimal
labor, best-in-class energy efficiency, and architectural-quality
light to deliver an exceptional value for customers.
The ECO Series retrofit offers out-of-the-box dimming compatibility
using 0-10-volt controls and features a one-piece design that is
quick and easy to install into existing recessed frames.
FEATURES :
• Universal voltage (120V-277V)
• Mounts into existing recessed frame
• Supplied with optional retaining clips if existing frame does
not have adequate friction springs to secure reflector
• cULus listed for damp location use
• CRI: ≥80
• PF: ≥0.9
• Dimmable 0-10V to 10%
• Five year limited warranty
CONSTRUCTIONS:
• Supplied with an aluminum reflector in a haze finish
• External driver for easy retrofit and maintenance
D
A
M
P
L
I
S
T
E
D
7.87” 200mm
0.16” 4mm
6.42” 163mm
5.67” 144mm
9.44” 240mm
7.99” 203mm
6.33” 144mm
0.19” 5mm
6”
8”
