Specification Sheet

Phone: [phone] | Fax: [phone] | Web: www.maxlite.com | E-mail: [e-mail]
MAX18054
Revised:10/09/18
Page: 1 of 3
PROJECT NAME:_____________________________ CATALOG NUMBER:__________________________
NOTES:______________________________________FIXTURE SCHEDULE:_________________________
PRODUCT DESCRIPTION:
The LSV Vapor Tight Fixture is a cost effective LED vapor
tight xture. The product is constructed with a full length
polycarbonate lens, and a one piece polycarbonate body.
Product applications include utility lighting, parking garage
lighting, stairwell lighting, and low bay lighting
FEATURES:
• 120-277V Standard, 347V available
• 0-10V dimming standard
• CRI ≥80
• L70: 100,000
• Ceiling, wall, or suspension mounted
• Optional motion sensors and battery backup options
available
• Suitable for wet locations
• IP65 rated with hermetic sealing
• Five year limited warranty
• Assembled in USA available upon request
• NSF Certied
CONSTRUCTION:
• 2ft Product Dimensions: 26” x 6.75” x 4.75” (L x W x H)
• 4ft Product Dimensions: 50” x 6.75” x 4.75” (L x W x H)
• Non-corrosive polycarbonate (PC) housing
• Stainless Steel spec grade hasps and clips
• Back and end knockouts
• White nish standard
NOTES:
1. In the event of a power failure, the battery backup unit switches to emergency mode (700
lumen output) and operates the xture for a minimum of 90 minutes
2. 2’ product available in 25W only
3. LSV4U2540 DLC Qualied at 120V only
4. 347V models not DLC Qualifed
5. 2’ models not NSF certied
LED VAPOR TIGHT LINEAR FIXTURES
LSV SERIES GEN 4
LS V
FAMILY
TYPE SIZE VOLTAGE
NOMINAL
WATTAGE
CCT OPTIONS
LS=
Linear
Series
V=
Vapor
Tight
4=
2=
4 ft
2 ft
U=
3=
120-277V
347V
25=
35=
45=
25W
35W
45W
40=
50=
4000K
5000K
(OMIT)=
EM=
MS=
MSO=
MSV=
None
Battery Backup Unit
Bi-Level Motion Sensor
On/Off Motion Sensor
Bi-Level Motion Sensor w/ Remote Control
Capability
MODEL SELECTION (Full list of order codes on pg. 2)
Typical order example: LSV4UW3540EMMSO
0
-
1
0
V
D
I
M
M
I
N
G
ACCESORIES
ORDER
CODE
MODEL
NUMBER
DESCRIPTION
74139 MLCHKLSV15 Cable Kit 15’ Loop x Loop 1 Pair
108133 RMHYTHRC-05 Remote Control for MSV Sensor Commissioning
LINE DRAWING:
50”
4.75”
6.75”
Side View
Bottom View
Top View
Right Side View
48” LED Vapor Tight
w/ Translucent Lens
