Specification Sheet

Phone: [phone] | Fax: [phone] | Web: www.maxlite.com | E-mail: [e-mail]
MAX15049
Revised: 08-09-16
Page: 2 of 2
POLYGON
TM
LINEAR LED
PARKING GARAGE FIXTURE
LSP SERIES
SPECIFICATIONS:
LSP4805SU44DVXXPKG LSP9605SU55DVXXPKG LSP9605SU80DVXXPKG
ITEM SPECIFICATION DETAILS DETAILS DETAILS
GENERAL
PERFORMANCE
Spacing Criteria
Contact MaxLite for layout details
Lumens Delivered (lm)
4,153 4,106 5,700 8,010 9,365 10,498
Efcacy (lm/W)
106.0 106.0 95.0 137.0 119.0 133.0
CCT
3500K 5184K 3500K 5000K 3500K 5000K
Lumen Maintenance (L70)
50,000 Hrs
ELECTRICAL
Power Consumption
39.2/40 60.0/58.5 78.8/79
Input Voltage (V)
120-277V
Power Factor
>.99 @ 120VAC; >.91 @ 277VAC
Line Voltage linking 15 units max 12 Units max 10 Units max
Operating Cycle
50/60 Hz
Control
0-10v Three wire lead; Dimming range 30%-100%
SENSOR
Linking 30 Fixtures 20 Fixtures* 10 Fixtures*
Type Omni-directional PIR with Daylight Harvesting
Max load MAX 800W
Ambient Level Selectable (3) Level
Time Delay Selectable (1 min - 30 min)
Dimming Levels 0 / 33% / 50% Selectable
PHYSICAL
Dimensions 46.3” L x 4.25” W x 1.8” H 92.7” L x 4.25” W x 1.8” H
Weight 4.75 lbs 9.5 lbs
Housing 6063 Aluminum
Lens Translucent White Polycarbonate
Mounting Surface or Suspended
Operating Temperature -20ºC to 40ºC (-4ºF to 104ºF)
CERTIFICATION
Certication
UL, FCC, LM80
Material Usage Damp (Covered)
Environment
IESNA LM-80
Warranty
5 Year
