CONN 2.1MM/5.5MM PWRJACK RT
ANGLE PCB, closed frame, high
current 24VDC@5A also requires 5V
ACDC adapter INPUT 100-240VAC
50-60HZ 0.6A OUTPUT DC 5V 2.6A.
PN DMS050260-P5P-SZ. MODEL 3Z-
161WP05
CUI, INC PJ-002AH
JB03 1
PLUG, SMD, 50 PIN, 2 ROW
VERTICAL
Samtec SFM-125-L2-S-D-LC
U02, U03 2 SFP host / receptacle PARTS_KIT SFP_HOST-TYCO
HB01, HB02, HB03, HB04, HB05 5 Rubber bumper 0.5 inch NA SJ5518-0
YB01 1
OSCILLATOR, CRYSTAL CLOCK,
3.3V - 19.44 MHZ
SaRonix
SOCKET+NTH089A
3-19.44
YB02 1
OSCILLATOR, CRYSTAL CLOCK,
3.3V - 77.76 MHZ
SaRonix
SOCKET+NTH089A
3-77.7600
T01 1
XFMR, OCTAL T3/E3, 1 TO 2, SMT
32 PIN
Pulse T3049
CB145, CB157, CB171, CB174,
CB176
5 D CASE TANT 470uF 6.3V 20% KEM T491D477M006AS
J22, J25, J26, J27, J28, J29 6
L_2 PIN HEADER, .100 CENTERS,
VERTICAL
Samtec TSW-102-07-T-S
J06, J07, J12, J13, J14, J15, J17,
J18, J19, J20, JB04, JB07
12
TERMINAL STRIP, 6 PIN, DUAL
ROW, VERT
Samtec TSW-103-07-T-D
J16, J31, JB01 3
L_TERMINAL STRIP, 10 PIN, DUAL
ROW, VERT
Samtec TSW-105-07-T-D
J02, J05, J08 3
TERMINAL STRIP, 16 PIN, DUAL
ROW, VERT
Samtec TSW-108-07-T-D
