DS33M33DK
Rev: 102108 19 of 48
J01, J30 2 HEADER, 14 PIN, DUAL ROW, VERT Samtec
HDR-TSW-107-14-
T-D
J11 1
CONNECTOR, SINGLE LEVEL,
GIGABIT RJ-45, 10 PIN
Halo
Electronics
HFJ11-1G02E
U08 1
IC, FPGA, 1.2V, 20X20 TQFP, 144
PIN
LAT LFE2-6E-5TN144C
U01 1
IC, FPGA, 1.2V, 20X20 TQFP, 144
PIN
LAT LFEC3E-3T144C
DS04, DS05, DS28 , DS19, DS20,
DS21, DS22, DS23, DS24, DS25,
DS26, DS27
12 L_LED, RED, SMD Panasonic LN1251C
DS02, DS03, DS08, DS09, DS29 ,
DS18, DS30, DS32
8 L_LED, GREEN, SMD Panasonic LN1351C
UB09 1
IC, LINEAR REG 1.5W, 1.8V or Adj,
1A, 16TSSOP-EP
Maxim MAX1793EUE-18
UB08 1
IC, LINEAR REG 1.5W, 2.5V or Adj,
1A, 16TSSOP-EP
Maxim MAX1793EUE-25
UB10, UB11, UB13 3
IC, LINEAR REG 1.5W, 3.3V or Adj,
1A, 16TSSOP-EP
Maxim MAX1793EUE-33
UB01, UB03 2
IC, LDO REGULATOR WITH
RESET,1.20V OUTPUT 300 MA, 6
PIN SOT23
Maxim MAX1963EZT120-T
UB07 1
MICROPROCESSOR VOLTAGE
MONITOR, 3.08V RESET, 4PIN
SOT143
Maxim MAX811TEUS-T
U09 1 MMC2107 PROCESSOR Motorola MMC2107
J03, J04, J23 3
TERMINAL STRIP, 10 PIN, DUAL
ROW, VERT
Digi-Key S2012-05-ND
J33 1 100 MIL 2*7 POS JUMPER NA NA
J35 1 TYPE B SINGLE RT ANGLE, BLACK Digi-Key WM17108-ND
JB08 1 100 MIL 2 POS JUMPER NA NA
See next row (begins with JP01) 27 100 MIL 3 POS JUMPER NA NA
JP01, JP02, JP03, JP04, JP05, JP06, JP07, JP08, JP09, JP10, JP11, JP12, JP13, JP14, JP15, JP16, JP17, JP18, JP19,
JP20, JP21, JP22, JP23, JP24, JP25, JP26, JPB01
TPB01, TPB02, TPB03 3
TEST POINT, 1 PLATED HOLE, DO
NOT STUFF
NA NA
U06 1
DOUBLE DATA RATE (DDR) SDRAM
2-2-2 TIMING 256MBITX16 TSSOP
MICRON
MT46V16M16TG-
75E
U11, U12 2 CYPRESS SRAM 4Mbit*8 CYPRESS
CY62148DV30L-
70SXI
UB14 1
Dual RS-232 transceivers with 3.3V/5V
internal capacitors
MAXIM MAX3233E
JB02 1
TEST POINTS FOR SMD 50 PIN, 2
ROW VERTICAL
NA
NA_NOTPOPULAT
ED
UB05 , UB12 2 HIGH SPEED INVERTER FAIRCHILD NC7SZ86
J24 1
NON POPULATED HEADER, 14 PIN,
DUAL ROW, VERT
Samtec
NOPOP-HDR-TSW-
107-14-T-D
JB05, JB06 2
DO NOT POPULATE L_2 PIN
HEADER, .100 CENTERS, VERTICAL
Samtec
NOPOP-TSW-102-
07-T-S
J09, J10 2
TERMINAL STRIP, 6 PIN, DUAL
ROW, VERT NOT POPULATED
Samtec
NOPOP-TSW-103-
07-T-D
J21 1
NOPOP TERMINAL STRIP, 16 PIN,
DUAL ROW, VERT
Samtec
NOPOP-TSW-108-
07-T-D
YB04 1
OSCILLATOR, CRYSTAL CLOCK,
5.0V - 34.368 MHZ
SaRonix NTH089AA-34.368
YB05 1
SOCKETED OSCILLATOR, CRYSTAL
CLOCK, 3.3V - 25.000 MHZ
SaRonix
NTH089AA3-
25.000+SOCKET
YB03 1
OSCILLATOR, CRYSTAL CLOCK,
3.3V - 44.736 MHZ
SaRonix NTH089AA3-44.736
