Datasheet

PROCESS: BiCMOS
Chip Information
MAX6800/MAX6801/MAX6802
3-Pin, Low-Power
µP Reset Circuits
6 _______________________________________________________________________________________
* Sample stock is generally held on all standard versions.
Selector Guide (Standard Versions * )
PART OUTPUT STAGE NOMINAL V
TH
(V)
MIN RESET
TIMEOUT (ms)
SOT
TOP MARK
MAX6800UR26D3-T Push/Pull RESET 2.63 100 FZIE
MAX6800UR29D3-T Push/Pull RESET 2.93 100 FZIF
MAX6800UR31D3-T Push/Pull RESET 3.08 100 FZIG
MAX6800UR44D3-T Push/Pull RESET 4.38 100 FZIH
MAX6800UR46D3-T Push/Pull RESET 4.63 100 FZII
MAX6801UR26D3-T Push/Pull RESET 2.63 100 FZIK
MAX6801UR29D3-T Push/Pull RESET 2.93 100 FZIM
MAX6801UR31D3-T Push/Pull RESET 3.08 100 FZIN
MAX6801UR44D3-T Push/Pull RESET 4.38 100 FZIO
MAX6801UR46D3-T Push/Pull RESET 4.63 100 FZIP
MAX6802UR26D3-T Open-Drain RESET 2.63 100 FZIQ
MAX6802UR29D3-T Open-Drain RESET 2.93 100 FZIR
MAX6802UR31D3-T Open-Drain RESET 3.08 100 FZIS
MAX6802UR44D3-T Open-Drain RESET 4.38 100 FZIT
MAX6802UR46D3-T Open-Drain RESET 4.63 100 FZIU
Package Information
For the latest package outline information and land patterns
(footprints), go to www.maxim-ic.com/packages
. Note that a
“+”, “#”, or “-” in the package code indicates RoHS status only.
Package drawings may show a different suffix character, but
the drawing pertains to the package regardless of RoHS status.
PACKAGE
TYPE
PACKAGE
CODE
OUTLINE
NO.
LAND
PATTERN NO.
3 SOT23 U3-1 21-0051 90-0179
