Datasheet

MAX1153/MAX1154
Stand-Alone, 10-Channel, 10-Bit System Monitors
with Internal Temperature Sensor and V
DD
Monitor
______________________________________________________________________________________ 29
REFERENCE
TEMP
SENSOR
MUX
DIGITAL BLOCK
CHANNEL REGISTERS
GLOBAL REGISTERS
SPI
INTERFACE
μC
VREF
INT
SPI I/F
GND
V
DD
+V
48V
AIN0
AIN1
AIN2
AIN3
AIN4
AIN5
AIN6
AIN7
REMOTE TEMP
ADC
POWER SUPPLY
-5V +5V +3V
MAX1153
MAX1154
Typical Operating Circuit
Chip Information
PROCESS: BiCMOS
Package Information
For the latest package outline information and land patterns, go
to www.maxim-ic.com/packages
. Note that a “+”, “#”, or “-” in
the package code indicates RoHS status only. Package draw-
ings may show a different suffix character, but the drawing per-
tains to the package regardless of RoHS status.
PACKAGE TYPE PACKAGE CODE DOCUMENT NO.
16 TSSOP U16-1
21-0066
