Manually Triggered Conversion
(Command Code = 0000)
Before beginning a manual conversion, ensure the
scan mode bit in the setup register is zero, because a
logic 1 disables manual conversions. The address bits
in a Manually Triggered Conversion command select
the input channel for conversion (see Table 3). When
performing a differential conversion, use the even chan-
nel address (AIN0, AIN2, AIN4, AIN6); the command is
ignored if odd channel addresses (AIN1, AIN3, AIN5,
AIN7) are used for a differential conversion.
After issuing a Manually Triggered Conversion com-
mand, bring CS high to begin the conversion. To obtain
a correct conversion result, CS must remain high for a
period longer than the reference power-up time (if in
power-down mode) plus the conversion time for the
selected channel-configured conversion type (voltage
or temperature). The conversion’s result can then be
read at DOUT by issuing a Read Current Data Register
for Selected Channel command, addressing the con-
verted channel. See Table 3 for channel addresses.
Table 2. Command Description
DATA BYTES AFTER
COMMAND WORD
COMMAND
WORD
BYTES TO
DIN
BYTES FROM
DOUT
COMMAND DESCRIPTION
0000#### 0 0 Manually Triggered Conversion
0001xxxx 0 3 Read Alarm Register
0010#### 0 2 Read Current Data Register for Selected Channel
0011#### 0 20 Read Current Data Register for All Channels
0100#### 0 5 Read Configuration Register for Selected Channel
0101xxxx 0 5 Read Global Configuration Registers
0110xxxx N/A N/A Reserved
0111xxxx 0 0 Reset
1000#### 0 0 Clear Alarm/Fault for Selected Channels
1001xxxx 0 0 Clear Alarm/Fault for All Channels
1010#### 2 0 Write Current Data Register for Selected Channel
1011xxxx 20 0 Write Current Data Registers for All Channels
1100#### 5 0 Write Configuration Registers for Selected Channel
1101xxxx 5 0 Write Global Configuration Registers
1110xxxx N/A N/A Reserved
1111xxxx N/A N/A Reserved
#### = Channel address code, see Table 3.
xxxx = These bits are ignored for this command.
Table 3. Channel Address
ADDRESS IN COMMAND INPUT
0000 Internal temperature
0001 V
DD
0010 AIN0
0011 AIN1
0100 AIN2
0101 AIN3
0110 AIN4
0111 AIN5
1000 AIN6
1001 AIN7
1010 Reserved
1011 Reserved
1100 Reserved
1101 Reserved
1110 Reserved
1111 Reserved
