DS1347
Low-Current, SPI-Compatible
Real-Time Clock
Revision History
REVISION
NUMBER
REVISION
DATE
DESCRIPTION
PAGES
CHANGED
0 8/11 Initial release —
1 1/12 Removed all references to the DS1346 All
2 2/12
Removed the external oscillator text from the X1 pin description in the Pin
Description table
5
3 1/13
Moved Crystal Characteristics table below notes; added POR content for
clock/calendar registers.
3, 15
4 11/13 Updated CS timing in Figures 1a, 1b, 2a, and 2b; replaced Figure 3 13, 14
