User Manual

T E C H N I C A L S P E C I F I C A T I O N S
Product User Guide
44
iDL300 System Specifications
Specification
Details
Core
Processor
PXA270 @ 520MHz
Memory
128 Mbytes SDRAM
1 Gbytes Flash
4 Gbytes SDHC card (expandable to 32 Gbytes)
Operating system
Windows CE 6.0
Peripherals
Fingerprint reader
Futronic FS89 optical reader (24.3 x 16.2 mm)
FBI IAFIS certified (to be tested)
FIPS 201 approved (to be tested)
Barcode reader
All common 1D & 2D barcodes
Camera
1.3 MP colour
FIPS compliant for facial image capture,
LumiLED illumination
Contactless card reader
ISO 14443 proximity and ISO 15693 vicinity card reader
FIPS 201 approved (To be tested)
Contact card reader
Full size ISO 7816 smart card reader
FIPS 201 approved (To be tested)
SAM socket
ID0 size ISO 7816 smart card interface
User interface
Display
3.7” (480x640) ¼ VGA landscape format LCD, 65K colours
Sunlight readable, active TFT, backlit
Touch screen
Resistive touch screen
Stylus
Keyboard
Power button
Two scan buttons on sides
Sound
Speaker for user feedback, Satellite Navigation applications
Communications
USB
USB full speed host, 250mA max supply, supports mass storage and other devices including
keyboard and mouse.
USB full speed slave, compatible with USB 2.0
WPAN
Class 2 Bluetooth 2.0 / 2.1 + EDR
WLAN
802.11 b/g WiFi
WWAN
Dual-Band HSPA/WCDMA and Quad-Band GSM/GPRS/EDGE
HSDPA, HSUPA, UMTS, EDGE, GPRS, GSM
SIM card
Power
Main Battery
Removable 2850mAh Lithium polymer battery
Fuel gauge
Backup Battery
Hot-swap supported via internal super-capacitor
Certifications
Regulatory
FCC, CE
Mobile ID
FBI IAFIS certified to SAP 20 (To be tested)
Options
GPS
50 channel high sensitivity GPS receiver
Microphone
Built in microphone
