Working with the iDL300 batteries
Using the Battery Charger
The Battery charger can be used to charge an iDL300 battery outside of the iDL300 device. To operate, the battery charger requires a 12V 2A
universal AC power supply unit (PSU) supplied with the iDL300.
Connecting power to the battery charger
Place the charger on a flat, level surface away from sources of heat and moisture. Plug the supplied USB to Mini-USB cable into the USB connector
on the 12V 2A universal AC Power Supply Adaptor. Then connect the AC adapter to a mains AC power source. Connect the functional PSU into the
battery charger by plugging the Mini USB into the connecter and then switch the mains AC power source on.
Inserting a battery and Charging
The iDL300 is supplied with a 2850 mA/h Lithium polymer battery. An optional extended 5700 mA/h Lithium polymer battery is available.
In order to charge a battery via the battery charger, place the battery into the Battery Bay ensuring that the 3-way connector is fully seated in the
battery charger as shown above.
The LEDs of the charger will provide status information and the charger will automatically begin charging. Charging a battery via the charger will
take up to three (3) hours.
Use only the correct batteries, PSU and battery charger supplied by a MaxID dealer. The use of other equipment can cause
permanent damage to the iDL300 and render the warranty void. For correct supplies contact a MaxID Dealer or visit
www.maxid.net
