Instruction manual

/
L-4 GRASSHOPPER
MAJOR COMPONENTS
Fuselage and wing set Main-gear’s struts
Stickers Fiberglass Cowl
Assembly Parts
(Listed in table, below)
1:
Elevator coupler
8:
Hook & loop straps
15:
Door handle
22:
Motor mounting box
2:
Cockpit braces
9:
Mains gear wheel
16:
Spare wood
23:
Windshield
3:
Throttle tube
10:
Tail
strut &
wheel
17:
Spring
24: Throttle pushrod
4:
Aileron pushrods
11:
CA hinges
18:
Tank plumbing
25: Wingrods
5:
Engine mounts
12:
Strut braces
19:
Control horns
26: Struts
6:
Glow
-
fuel tank
13:
Spring retainers
20:
EZ Links (2 bags)
See
www.maxfordusa.com
for upgrade item details
7:
8
-
in springs
14:
Servo mounts
21:
Screws, nuts
,
bolts
, etc.
(2 bags)
Optional upgrades:
· Prepainted detailed true-to-scale dashboard
and throttle control
· Dummy engine
· 40-sized floats
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
