6.5) Parts List
>upright cycle
MX-U5
NO. DESCRIPTION SPECIFICATION
AG1
Handlebar Set CB32 (w/HP) w/Texture
AG1 Handpulse Grip Set CB32 (w/HP) w/o Texture
AN1
Console Set CB32 (English-Metric)
AN1 Console Set CB32 (Netherlands-Metric)
AN1 Console Set CB32 (Germany-Metric)
AN1 Console Set CB32 (Italy-Metric)
AN2 Hand Pulse Grip Set CB32 (w/Texture)
AN2 Handpulse Grip Set CB32 (w/o Texture)
AU1 Tension Wheel Set CB32
Q01 Right Side Cover Set CB32
Q02 Left Side Cover Set CB32
R01 Drive Axle Set CB32
R04 Fixing Bearing Housing Set CB32
R05 Slide Bearing Housing Set CB32
T01 Pedal Axle Set CB32
AB1 Main Frame CB32 (Anthracite)
AC1 Console Mast CB32 (Anthracite)
AC2 TV Bracket (With Cables) Matrix U5 (CB32)
AC5 TV-Support Bracket Matrix U5 (CB32)
AD1 Seat Mast CB32 (Halftone Printing)
AZ1 Hardware Kit Include Hand Tools (Purple Round Sticker)
B23 C Clip WUSN-4039
B24 Screw, Oval Head M5x0.8Px12L (Bed)
B25 Nylon Nut M5x0.8P
B28 C Clip USN-4043
C04 Outer Tube Of Console CB32-C04
C06 Console Lower Cover-Lh ABS (CB32-C06B)
C07 Console Lower Cover-Rh ABS (CB32-C07C)
C08 Console Cover NYLON
C12 Screw, Round Hex Socket M8x1.25Px50L (30L)
C14 Nylon Nut M8x1.25P (Bed)
C15 Screw, Round Tapping 4x12L
C19 Screw, Round Hex Socket M8x1.25Px60L
C22 Spring Washer SW8 8.2x15.4x2t
D03 Seat Mast Bushing Nylon
D04 Lower Bushing Of Seat Mast Nylon (Iron-Tin Color)
D05 Seat Post Adjusting Pin Set M16 (CB32-D05C)
D06 Seat Pad Air Cushion (CB32-D06M)
D07 Nylon Nut M8x1.25P (Chromate Treatment)
D08
Spring Washer M8 (Zinc Plating)
D09 Screw, Plain Head M4x0.7Px10L
D10 Bushing POM (JS001-11)
D11
Scr
ew, Oval Head M6x1.0Px50L (10L)
NO. DESCRIPTION SPECIFICATION
D12
Nylon Nut M6x1.0P (Chromate Treatment)
D15 Nylon Nut M4x0.7P
G08
Screw, Inner Hex Socket M8x1.25Px15L
J01 Rear Stabilizer CB32
J02 Front Stabilizer-RH CB32
J03 Front Stabilizer-LH CB32
J04 Adjustable Foot Pad
J05 Screw, Oval Hex Socket M8x1.25Px20L (Bed)
J06 Screw, Oval Hex Socket M10x1.5Px20L
L01 Mobile Wheel NYLON+30%FIBER
L02 Screw, Oval Hex Socket M8x1.25Px70L(12L)
L03 Flat Washer 8.2x18x1.4t (Bed)
L04 Nylon Nut M8x1.25P (Bed)
N10 Watter Bottle Holder ABS
N15 Overlay MX U5/R5/E5 (U.S.A.)
N15 Overlay MX U5/R5/E5 (Holland)
N15 Overlay MX U5/R5/E5 (Germany)
N15 Overlay MX U5/R5/E5 (Italy)
N20 2-in-1 Polar Receiver POLAR 39021539.00 (RB59-P12A)
N21 Sensor Grip CB32-N21F
N22 Heartbeat Sensor Plate 101.5x32 (SUS304) (w/Texture)
N22 Heartbeat Sensor Plate 101.5x32 (SUS304) (w/o Texture)
N23 End Cap, Hand Pulse Grip Nylon
N26 Screw, Round Tapping M3x0.5Px35L
N27 Hex Nut M3x0.5P
P01 Console Cable 1050(XAP-07V-1+H6657R1-8+SMR-08V-B)
P02 E-Port Power Connecting Cable 350 (XAP-02V-1+SMP-02V-BC)
P03 E-Port TV Signal Cable 350(5C-2V+5C-2V)
P04 Connecting Cable Of Controller 600(3.96-5P+HL20P-03)
P05 Power Resistance 400W10_-200(3.96-4P White VH)
P06 Hand Pulse Cable 700 (H6657R1-2+110xF)
P11 Adapter 5C-2V (w/Nut)
P16 Ferrite Cord FH0900B-2
P18 Earphone Extended Cable 185(3.5 3-D Earphones+
Microphone F*Base 3P)
P19 Power Transferred Cable 1200(XAP-02V-1+H6657R1-2)
P20 E-Port Control Board w/PCB Board- DC Bracket & Adapter
P21 TV Signal Cable 1250(RG-6)X2 (w/Adapter x1)
P23 Console Mast Cable 900 (SMP-08V-BC+H6657P1-8)
P25
TV Power Cable 1250 (SMR-02V-B)x1
P37 End Protect Bushing (KSS) EP-1113(BUY-OUT)
Q01 Right Side Cover ABS
Q02
Left Side Cover
ABS
