6.2) Parts List
>recumbent cycle
MX-R5
NO. DESCRIPTION SPECIFICATION
AG1
Hand Pulse Grip Set RB50 (w/HP) w/Texture
AN1 Console Set RB50 (English-Metric)
AN2
Hand Pulse Grip Set CB32 (w/Texture)
AN2 Hand Pulse Grip Set CB32 (w/o Texture)
AU1 Tension Wheel Set RB50
D13 Back Pad Set RB50
D23 Seat Roller Set RB50
D25 Adjustable Roller Set RB50
Q01 Right Side Cover Set RB50
Q02 Left Side Cover Set RB50
R01 Drive Axle Set RB50
R04 Slide Bearing Housing Set CB32
R05 Fixing Bearing Housing Set CB32
T01 Pedal Axle Set CB32
AB1 Frame Set RB50 (Metal Color)
AC1 Console Mast Set RB50 (Metal Color)
AC2 Front Handlebar Set PVC
AC3 TV Bracket (with Cables) MATRIX R5(RB50)
AC4 Console Fixed Plate
AD1 Slide Seat Set RB50 (Metal Color)
AD2 Back Pad Mast Set RB50 (Metal Color)
AD6 Back Pad with Lumbar Set
AZ1 Hardware Kit Include Hand Tools (Purple Round Sticker)
C01 Console Mast
C10 Front Handlebar Axle SS41
C11 Console Lower Cover-RH ABS (Knurled on Surface)
C12 Console Lower Cover-LH ABS
C13 Spacer 20x26x15L
C14 Console Mast Sleeve Nylon
C17 Screw, Inner Hex Socket M8x1.25Px15L
C18 Rivet (Brass Inserts Nut) ALS7-8125-3.8 (0.5-3.8)
C19 Screw, Oval Hex Socket M8x1.25Px20L
C20 Screw, Round Tapping 4x10L
C21 Fixed Nut AN04 (M20x1.0Px6t) (Bed)
C22 Front Handlebar Cover PVC
C23 Console Cover Nylon
C24 Flat Washer 8.2x_18x1.4t (Bed)
C25 Screw, Oval Hex Socket M8x1.25Px15L
C30 Screw, Round Hex Socket M8x1.25Px50L (30L)
C31
Nylon Nut M8x1.25P (Bed)
C32 2-E.ND Round Key 6x6x16L
D04 Adjust Lever SS41
D11
Seat Pad
NO. DESCRIPTION SPECIFICATION
D12
Seat Pad Fixed Plate SPC (Zinc Plating)
D18 U Sleeve
D21
Knob Nylon + Fiber (Red #1797)
D23 Roller POM
D24 Roller Axle SS41
D25 Adjustable Roller POM
D26 Adjustable Roller Axle SS41
D29 Adjustable Positioning Board SPC
D30 Located Block S45C
D31 Adjustable Spring
D32 Handlebar Long Pearl #4 (Red)
D33 Nylon Nut M6x1.0P (Bed)
D34 Nylon Nut M8x1.25P (Bed)
D35 C Clip-External S-10
D36 Settle Bolt M12x1.75Px12.0L
D37 Screw, Round Hex Socket M5x0.8Px25L
D38 Screw, Round Hex Socket M6x1.0Px30L(15L)
D39 Screw, Plain Head M5x0.8Px10L
D40 Screw, Round Tapping M5x0.8Px12L
D41 Spiral Shells Axle Cover ABS
D43 Screw, Inner Hex Socket M8x1.25Px15L (Bed)
D44 Screw, Oval Hex Socket M8x1.25Px50L
D46 Arc Washer 8.2x18x.15t
D48 Screw, Round Tapping 3x12L
D51 Front Fixed Board for Cable SPC
D52 Steel Cable Fixed Bracket SPC
D53 Foam Grip 25.0x31.0x240L
D54 Foam Grip PVC Sleeve (Red #1797)
D55 Spring Washer SW8 8.0x17.0x1.5t
D56 Screw, Shallow Hex Socket M8x1.25Px15L (Bed)
D57 End Cap PVC Black
F01 Rear Stabilizer Set CB32
F02 Front Stabilizer-RH Set CB32
F03 Front Stabilizer-LH Set CB32
F04 Adjustable Foot Pad No Turn
F05 Screw, Oval Hex Socket M8x1.25Px20L (Bed)
F06 Screw, Oval Hex Socket M10x1.5Px20L
H01 Slide Rail AL
H02 Rail Fixed Plate SPC
H03
Screw, Round Tapping 3x10L
H04 Rail End Cap ABS
H05 Stop Wheel Shaft SS41(Zinc Plating)
H06
Seat Pad Stopper Roller
PU
