O W N E R ’ S M A N U A L
C Y C L E S
Table of Contents 1.0) 1.1) 1.2) 2.0) 2.1) 2.2) 3.0) 3.1) 3.2) 3.3) 4.0) 4.1) 4.2) 4.3) 4.4) 4.5) 5.0) 5.1) 5.2) 6.0) 6.1) 6.2) 6.3) 6.4) 6.5) 6.
1) Important Safety Instructions R E A D A N D S AV E T H E S E I N S T R U C T I O N S SETTING UP THE CYCLE • This Cycle is intended to for commercial use Assembly instructions have been provided with your Cycle. For your safety, please read and follow each of the steps in the assembly guide. To obtain a copy of the assembly guide, please contact MATRIX FITNESS SYSTEMS. • To insure your safety and protect the equipment, read all instructions before operating the MATRIX Cycle.
2) Using Manager Preference Mode 2.0 USING MANAGER PREFERENCE MODE UNIT 1 Your MATRIX Cycle is designed to allow you to customize settings for your preferences and diagnostics. The Manager Preference Mode can only be accessed while the Cycle is powered up. Follow the instructions to adjust the Cycle computer for your desired settings. STEP 1 Power up the Cycle and Hold the UP and DOWN arrow keys for 3 seconds.
3) Adjusting the Seat Height 3.0 A D J U S T I N G T H E S E AT H E I G H T Your MATRIX Cycle is designed for ease of use. We have incorporated seat height adjustments that are easily located and simple to adjust. 3.1 U P R I G H T S E AT H E I G H T To adjust the seat height on the Upright Cycle, locate the red pull pin before you mount the Cycle. To lower the seat down, pull the red knob while holding the seat with the other hand and slide up or down accordingly.
4) Using the Cycle or Recumbent 4.1 CONSOLE DESCRIPTION STEP 1 Select Manual program button on left of panel. NOTE Press Enter or wait 5 seconds. Selecting START will start program. STEP 2 Select Time by using the UP or DOWN arrow keys. When finished NOTE Press Enter or wait 5 seconds. Selecting START will start program. STEP 3 Select Level by using UP or DOWN arrow keys. You can change the level at any time during workout. When finished, Press Enter or Wait 5 seconds.
4) Using the Cycle or Recumbent TIME Starting 3 Starting 2 Starting 1 P O L A R TA R G E T H E A RT R AT E Z O N E HR BEATS PER MINUTE 220 200 180 4.4 H E A R T R AT E C O N T R O L 160 140 For your convenience, MATRIX FITNESS CYCLES come standard with digital contact heart rate sensors and POLAR telemetry compatible. 120 100 Locate the metal sensors on the handrail of the Cycle. Notice there are two separate pieces of metal on each grip.
5) Equipment Specifications >recumbent cycle MX-R5 S P E C I F I C AT I O N S Product Name Foot Print Weight Max User Weight Frame Construction Self Contained Resistance Type Resistance Levels R5 49"H x 62"L x 25"W 132 lbs 400 lbs = 181 kg Aluminum/Steel Yes Generator 20 PROGRAMS One Button Quick Start Random (20 profiles) Target Heart Rate Interval Constant Watts Rolling Fat Burn Yes Yes Yes Yes Yes Yes Yes H E A R T R AT E Polar Telemetry Contact Heart Rate Yes Yes E N T E R TA I N M E N T R E A
5) Equipment Specifications > upright cycle MX-U5 S P E C I F I C AT I O N S Product Name Foot Print Weight Max User Weight Frame Construction Self Contained Resistance Type Resistance Levels U5 57"H x 44"L x 25"W 106 lbs 400 lbs = 181 kg Aluminum/Steel Yes Generator 20 PROGRAMS One Button Quick Start Random (20 profiles) Target Heart Rate Interval Constant Watts Rolling Fat Burn Yes Yes Yes Yes Yes Yes Yes H E A R T R AT E Polar Telemetry Contact Heart Rate Yes Yes E N T E R TA I N M E N T R E A
T H I S PA G E I N T E N T I O N A L LY B L A N K
6) Parts & Assembly >cycles MX-R5 and MX-U5
T H I S PA G E I N T E N T I O N A L LY B L A N K
6.1) MX-R5 Exploded View >recumbent cycle MX-R5 FASTENERS AND ASSEMBLY TOOLS WATER BOTTLE TV REFERENCE SKETCH DESCRIPTION QUANTITY N10 C27 C28 TV RACK AN1 P03 C17 BUTTON HEAD BOLT (M8 x 15L) 6 C20 BUTTON HEAD BOLT (M4 x 10L) 3 C24 WASHER (8.2x18.0x1.4t(BED) 2 C30 BUTTON HEAD BOLT (M8 x 50L) 2 D37 BUTTON HEAD BOLT (M8 x 25L) 2 D39 WASHER (SW5 5.1x9.3x1.
6.2) Parts List >recumbent cycle MX-R5 NO.
6.2 Parts List >recumbent cycle MX-R5 NO.
6.
6.
6.
6.
6.
6.
6.
6.
T H I S PA G E I N T E N T I O N A L LY B L A N K
6.
6.5) Parts List >upright cycle MX-U5 NO.
6.5) Parts List >upright cycle MX-U5 NO.
6.
6.
6.
6.
6.
6.
6.
M AT R I X F I T N E S S S Y S T E M S , I N C . 1 4 11 B R O A D W AY, N E A L B U Q U E R Q U E , N M 8 7 1 0 2 TOLL FREE 866.693.4863 FAX 5 0 5 . 2 4 2 . 4 7 2 5 w w w. m a t r i x - f i t n e s s .
