Technical data

Connections
SINAUT MICRO SC
8 C79000-G8900-C210
1.1 Communication via GPRS/GSM
Connection S7-200 Ù MICRO SC OPC routing software
Figure 1-1
GPRS communication S7-200 to SINAUT MICRO SC routing software
The central SINAUT MICRO SC OPC Routing Software can connect up to 256
remote controls S7-200 via GSM/GPRS.
The GSM/GPRS modems SINAUT MD720-3 connect the S7-200 controls to the
GSM/GPRS network.
The computer with the OPC Routing Software SINAUT MICRO SC is connected to
the GSM/GPRS network via the Internet.
So an OPC client has access to the OPC Server of the OPC Routing Software
SINAUT MICRO SC and can send / receive data to / from the remote controls.
Connection S7-200 Ù S7-200
Figure 1-2
S7-200 PPI
SINAUT
MD720-3
GPRS/
GSM
Internet
SINAUT
MICRO SC
OPC Server
OPC
Client
S7-200 PPI
SINAUT
MD720-3
GPRS/
GSM
Internet
SINAUT
MICRO SC
OPC Server
SINAUT
MD720-3
PPI S7-200
