Technical data

PLC Library SINAUT MICRO SC Flex Px

SINAUT MICRO SC

C79000-G8900-C210

8.2 Program module WDC_CONFIG_FLEX_Px

The module initialises the GRPS library, the PLC serial interface as well as the

GPRS modem.

Remark:

This module is to be called from the user program once per cycle.

Entering configuration parameters as string

A lot of the configuration parameters need to be entered as strings. These strings

need to be defined in the „data module“ of MicroWIN. The first Byte of the strings

contains the number of characters, the following Bytes contains the several

characters. The disposal of the parameter to the WDC_CONFIG_FLEX_Px module

is made by giving the reference to the corresponding string (&-operator) („Memory

address of the strings“).

Example:

Name of the modem at address VB1830.

Data module:

VB1830 6

VB1831 'modem1'

WDC_INIT_advanced

BUSY

IP_ADDRESS_CS DONE

DESTPORT_CS ABORTED

MODEM_NAME ERROR

MODEM_PASSWORD

APN

AP_USER

AP_PASSWORD

DNS

CLIP
