7.3 Program module WDC_SEND
This module processes all transmission tasks, initiated by the user program
(transmission impulse via START). Thereby a new transmission task is accepted
only then when no other task is active (BUSY must be 0). In the context of a
transmission task, it is possible to send a user data block with specification of
starting index and the length to the remote station.
While BUSY is set parameters of the module must not bee edited.
Remark:
This module is to be called from the user program once per cycle.
START
(BOOL)
A positive edge starts a new transmission task.
REMOTESTATIONADDRESS
(WORD)
Logical address of remote station, to which data should be sent and/or of which
data should be read.
DATA_START
(WORD)
Index of first data byte, to be sent and/or read.
E.g.: „1500“ for VB1500
WDC_SEND
START BUSY
REMOTESTATIONADDRESS DONE
DATA_START ABORTED
DATA_LENGTH ERROR
COMMAND
CURRENTTIME
