SINAUT MICRO SC configuration
SINAUT MICRO SC
C79000-G8900-C210
33
Settings
Figure 6-5
Language selection
Here the language used for the user interface can be selected. If you select an
other language it is active after a restart of the program.
Server Port
Here the TCP/IP port the GPRS modems use to connect to the server can be
configured. Possible values are between 1025 and 32767, the default is 26862.
Notice:
The port as configured here must match the setting in all PLC programs. Otherwise
there won’t be any connection between the station and the server!
After setting another server port you must restart the OPC server. Only then the
new setting becomes effective.
