Technical data

SINAUT MICRO SC configuration
SINAUT MICRO SC
C79000-G8900-C210
29
Station properties
Figure 6-2 Station properties
Station name
The specific station's name. This name must be unique over all stations. This name
must be provided in the OPC client for addressing the variables.
Station number
The station's unique number. This number must match the parameter
STATION_NUMBER when calling WDC_INIT. This number is used as destination
address with communication between PLCs. Possible values are between 1 and
65535, 0 is reserved for the server.
GPRS modem name
The name used by the GPRS modem for login at the server. This name must
match the parameter MODEM_NAME when calling WDC_INIT in the PLC
program. This name can't be edited.
