SINAUT MICRO SC configuration

SINAUT MICRO SC

28 C79000-G8900-C210

The menu bar provides the following options:

• File

• Exit

Closes the configuration tool (the server keeps on running).

• Extras

• Settings

System-wide settings

• ?

• Help

Opens this help

• Info

Shows license information

The buttons on the right side are for processing the connected stations.

Add

Adds a new station to the system. A dialog is opened, to edit the properties of the

new station.

Edit

Opens a dialog to edit the properties of the selected station.

Delete

Removes the selected station from the system.

Test status

Tests the current connection status of the selected station and opens a dialog to

show it.

The station status can also be tested by double clicking on a station in the list.

Status matrix

Shows the status of all configured stations in form of an open matrix.

Terminates the configuration tool.
