GSM data call S7-200 Õ Configuration computer
Figure 1-4
Remote configurations of the S7-200 by CSD data call
When a call goes to the connected control this control switches to the PPI mode.
Then a software update is possible.
GSM data call SINAUT MD720-3 (Service mode) Ù Configuration computer
Figure 1-5
Remote configurations of the SINAUT MD720-3 by CSD data call
A call to the Service Interface of the SINAUT MD720-3 must be established as
PPP-connection. Then it is possible to update the software of the device via FTP
protocol (refer to chapter 9.4 Service calls in OPC mode).
S7-200 PPI
SINAUT
MD720-3
GPRS/
GSM
Fixed net
Configuration
computer
S7-200 PPI
SINAUT
MD720-3
GPRS/
GSM
Fixed net
Configuration
computer
