Instruction Manual

Command Description Page
Hex Dec ASCII
0x57 87 “W” General Purpose Output On 31
0x58 88 “X” Clear Screen 19
0x60 96 “‘” Auto Repeat Mode Off 38
0x68 104 “h” Initialize Horizontal Bar 28
0x6D 109 “m” Initialize Medium Number 27
0x6F 111 “o” Place Medium Numbers 27
0x73 115 “s” Initialize Narrow Vertical Bar 29
0x76 118 “v” Initialize Wide Vertical Bar 29
0x7C 124 “|” Place Horizontal Bar Graph 28
0x7E 126 “~” Set Auto Repeat Mode 37
0x93 147 Set Remember 41
0x98 152 Set and Save Brightness 41
0x99 153 Set Brightness 40
0xA4 164 Setting a Non-Standard Baud Rate 16
0xC0 192 Loading Custom Characters 26
0xC1 193 Saving Custom Characters 25
0xC2 194 Save Startup Screen Custom
Characters
26
0xC3 195 Set Startup GPO state 32
0xC8 200 Dallas 1-Wire Transaction 33
0xCA 202 Data Lock 42
14 Appendix
14.1 Specifications
14.1.1 Environmental
Table 63: Environmental Specifications
Standard Temperature Extended Temperature
Operating Temperature 0
◦
C to +50
◦
C -20
◦
C to +50
◦
C
Storage Temperature -30
◦
C to +70
◦
C -30
◦
C to +70
◦
C
Operating Relative Humidity 90% max non-condensing
Vibration (Operating) 4.9 m/s
2
XYZ directions
Vibration (Non-Operating) 19.6 m/s
2
XYZ directions
Shock (Operating) 29.4 m/s
2
XYZ directions
Shock (Non-Operating) 490 m/s
2
XYZ directions
Matrix Orbital PK162-12 53
