Instruction Manual

Description
Syntax
Page
Save Startup Screen
Custom Characters
Hexadecimal 0xFE 0xC2 [refID] [data]
Decimal 254 194 [refID] [data]
26
Initialize Medium
Number
Hexadecimal 0xFE 0x6D
Decimal 254 109
ASCII 254 “m”
27
Place Medium Numbers
Hexadecimal 0xFE 0x6F [Row] [Col] [Digit]
Decimal 254 111 [Row] [Col] [Digit]
ASCII 254 “o” [Row] [Col] [Digit]
27
Initialize Horizontal Bar
Hexadecimal 0xFE 0x68
Decimal 254 104
ASCII 254 “h”
28
Place Horizontal Bar
Graph
Hexadecimal 0xFE 0x7C [Col] [Row] [Dir] [Length]
Decimal 254 124 [Col] [Row] [Dir] [Length]
ASCII 254 “|” [Col] [Row] [Dir] [Length]
28
Initialize Narrow Vertical
Bar
Hexadecimal 0xFE 0x73
Decimal 254 115
ASCII 254 “s”
29
Initialize Wide Vertical
Bar
Hexadecimal 0xFE 0x76
Decimal 254 118
ASCII 254 “v”
29
Place Vertical Bar
Hexadecimal 0xFE 0x3D [Column] [Length]
Decimal 254 61 [Column] [Length]
ASCII 254 “=” [Column] [Length]
30
13.4 General Purpose Output
Description
Syntax
Page
General Purpose Output
Off
Hexadecimal 0xFE 0x56 [Num]
Decimal 254 86 [Num]
ASCII 254 “V” [Num]
31
General Purpose Output
On
Hexadecimal 0xFE 0x57 [Num]
Decimal 254 87 [Num]
ASCII 254 “W” [Num]
31
