Instruction Manual

Description This command turns OFF general purpose output [num].
NOTE OFF means that the output is ground.
Remembered Yes
7.4 General Purpose Output On
Syntax
Hexadecimal 0xFE 0x57 [Num]
Decimal 254 87 [Num]
ASCII 254 “W” [Num]
Parameters
Parameter Length Description
Num 1 GPO number.
Description This command turns ON general purpose output [num]. The standard
GPO’s on the PK162-12 output 20mA of current at 5V.
NOTE The output is pulled high.
Remembered Yes
7.5 Set Startup GPO state
Syntax
Hexadecimal 0xFE 0xC3 [Num] [state]
Decimal 254 195 [Num] [state]
Parameters
Parameter Length Description
Num 1 GPO number.
state 1 Startup state (0: Off, 1: On)
Matrix Orbital PK162-12 32
