7 General Purpose Output
7.1 Introduction
General purpose outputs allow you to connect devices, such as LEDs, to the PK162-12 and supply them
with up to 20mA of current at 5V. The PK162-12 has 7 GPOs which are software controlled, with functions
to turn them on/off and set the power state for the next startup.
7.2 gpo_CMD_GPOtoggle()
7.2.1 Meta
Short Toggle Keypad/GPO mode
Remember Yes
7.2.2 Parameters
Mode 1 0: Keypad, 1: GPO
7.2.3 Description
The 162-12 uses the same port for keypad and GPO. This command will allow you to toggle the display
between GPO or Keypad mode. To use the GPO’s send cmd 254 / 37 / 1. To go to keypad mode, cmd 254 /
37 / 0 must be sent.
7.3 General Purpose Output Off
Syntax
Hexadecimal 0xFE 0x56 [Num]
Decimal 254 86 [Num]
ASCII 254 “V” [Num]
Parameters
Parameter Length Description
Num 1 GPO number.
