MOP-GL24064A Parallel Display Specifications Revision 1.
Revision History Revision 1.0 0.2 0.
Contents Revision History ............................................................................................................................................ 1 Contents ........................................................................................................................................................ 2 Features ........................................................................................................................................................ 3 Hardware ......
Features The Matrix Orbital Parallel display series offers a low cost display solution utilizing an industry standard communication interface for simple integration into a wide variety of new and existing applications. The Light Emitting Diode backlight with configurable brightness and voltage controlled contrast allows the MOP Liquid Crystal Display line to offer a professional display solution for any project. Hardware Drawing 180.0±0.5 176.0 154.8 132.2[V.V.] 127.16[A.A.] 65.0±0.5 56.8 54.0 39.2[V.V.
Instructions Outline The MOP-GL24064A is controlled using a standard T6963 compliant controller. The display is enabled by pulling the Chip Select (CS) pin low, communication to and from the device is controlled using the active low Write (WR) and Read (RD) inputs, and the unit may be reset by pulling the RST line low. Using Register Select, either the Command Register (C) or Data Register (D) is selected by toggling C/D high or low respectively.
Instruction Table Table 4: Parallel Instruction Table Instruction Set Cursor Pointer Set Offset Register Set Address Pointer Set Text Home Address Set Text Address Set Graphic Home Address Set Graphic Area Set OR Mode Set EXOR Mode Set AND Mode Text Attribute Mode Internal CG ROM Mode External CG RAM Mode Display Off Cursor On, Blink Off Cursor On, Blink On Text On, Graphic Off Text Off, Graphic On Text On, Graphic On 1-Line Cursor 2-Line Cursor 3-Line Cursor 4-Line Cursor 5-Line Cursor 6-Line Cursor 7-Lin
Timing Characteristics Table 5: Read and Write Operation Specifications Item C/D Set-Up Time C/D Hold Time CE, RD, WR Pulse Width Data Set-Up Time Data Hold Time Access Time Output Hold Time Symbol Min Typ Max Unit tCDS 100 － ns － tCDH 10 ns － － tCEr,tRD,tWR 80 ns － － tDS 80 ns － － tDH 40 ns － － tACC 150 ns － － tOH 10 50 ns － Conditions: Ta = -20℃ to 75℃, VSS = 0V, VDD = 5.0± 0.
Specifications Electrical Table 6: Electrical Characteristics Item Supply Voltage For Logic Supply Voltage For LCD (Contrast) Input High Voltage Input Low Voltage Supply Current (VDD=5V) Supply Voltage of Yellow-Green Backlight (126 Die) Supply Current of Yellow-Green Backlight (126 Die) Supply Voltage of White Backlight (4 Die) Supply Current of White Backlight (4 Die) Symbol VDD V0 VIH VIL IDD VLED ILED VLED ILED Min 4.5 -8.7 0.7 VDD VSS 9.0 3.8 0 3.0 0 Typ 5.0 -7.5 － － 9.9 4.2 － 3.2 － Max 5.5 -6.
Troubleshooting Power For your MOP Display to function correctly, appropriate power must be applied, often as indicated by the backlight illuminating or a darkening of the character spaces. Please refer to the power diagram below and reference all voltages to the specifications provided. Figure 7: Single Supply Configuration Figure 8: Dual Supply Configuration Display If your display is powered successfully, the backlight or contrast should be evident.
Ordering Part Numbering Scheme Table 10: Parallel Part Numbering Scheme MOP 1 - G 2 L 3 240 4 64 5 A 6 - B 7 Y 8 F 9 Y 10 - 2 11 2 12 N 13 - 3 14 I 15 N 16 Options Table 11: Parallel Part Options # 1 2 3 Designator Product Line Display Type Screen Type 4 Display Columns 5 Display Rows 6 Display Form Factor 7 IC Package 8 LCD Glass Type 9 Polarizer Style 10 Backlight Colour 11 Viewing Angle 12 Controller 13 14 Character Set Input Voltage 15 Temperature Range 16
