User`s guide

Sliders
3-25
Change the size or
position of the bar
On the Bar panel, use the BarInner and
BarOuter properties to define the width and
position of the bar in the direction perpendicular
to the linear scale. Use the
BarStart and
BarStop properties to define the length and
position of the bar in the direction of the linear
scale. These properties do not affect the
numerical values associated with the bar, only
the graphical depiction of the bar.
Change the colors of
the portions of the bar
on either side of the
knob
On the
Bar panel, use the OnColor and OffColor
properties to define the colors associated with
values below and above, respectively, the knob’s
current value along the bar.
Change the shape or
size of the knob
On the
Knob panel, use the Style property to
choose the shape. Use the
Inner Value and
Outer Value properties to determine the
thickness and position in the dimension
perpendicular to the sliding scale. Use the
Width
property to determine the width along the sliding
scale.
Label the knob by
displaying the
corresponding
number
On the
Digital panel, check the Enabled check
box.
Change the
appearance of the
knob label
On the
Digital panel. Then use Decimals to set
the number of digits after the decimal point,
Color to set the color of the number, and FontID
to refer to a previously defined font (on the
Fonts
panel).
Task (Continued) Description (Continued)
